Thread: Edixeon KLC8 versus Cree XR7090 in the Elly

  1. #1

    Wink2 Edixeon KLC8 versus Cree XR7090 in the Elly

    Edison Edixeon KLC8 (advertised 210 lumen @ 1000mAh) versus Cree BIN XR7090WT-U1-WD-P4-0-0001 (from DX) In the Elly (cheap) flashlight
    all with the original driver and one NiMH battery (1,2v)

    from left to right: original Elly led, Elly with Cree, Elly with the Edison





    underexposed




    The Edison's I have are a bit brighter than the Cree

    What I did like about the Edison’s (compared to the Cree) was
    • the price (they did cost me $6,30 a piece; emitter only)
    • the brightness;a full stop brighter than the original 1/3 stop brighter than the Cree
    • more compatible with Luxeon optics
    • will run as a direct drive bulb replacement in a 3D M*G realy BRIGHT! (stays pretty cool)
    What I did not like about the Edison’s was
    • the +positve pole on the backside(more difficult to install)
    • There is a colorshift in the beam (an ugly yellow corona!!!)
    • 1-2mm higher than a Cree
    • Lower build quality compared to the Cree

    I did also some measurements but my multimeter gave some odd value's so I skipped it
    the two Leds both pulled about the same.
    Maybe some runtimes /extra info later

    Cree star and a star with the KLC8

    Last edited by kanarie; 02-23-2007 at 06:24 PM.

  2. #2
    Flashaholic* nanotech17's Avatar
    Join Date
    Jul 2006
    Location
    N 03°13.884° / E 101°29.329°
    Posts
    2,151

    Default Re: Edixeon KLC8 versus Cree XR7090 in the Elly

    Hi ,
    Where did you get the KLC8 emitter for that price?



  3. #3

    Default Re: Edixeon KLC8 versus Cree XR7090 in the Elly

    Where did you get the KLC8 emitter for that price?
    a Dutch powerbuy
    thinking about asking the seller to start a powerbuy on this forum

  4. #4
    Flashaholic*
    Join Date
    Dec 2005
    Location
    socal
    Posts
    1,901

    Default Re: Edixeon KLC8 versus Cree XR7090 in the Elly

    kanarie,

    Can you expand on your comments:

    1. the -neg. pole on the backside(more difficult to install)
    - Why was the negative lead harder to install?

    2. Lower build quality compared to the Cree
    - What specific areas of the LED did you see the Edison as being lower quality than the Cree?

    I've been thinking about picking up some Edison Edixeons due to their lower price over SSC P4s, but have held off as they seem to have lower output relative to the SSC P4 (tho they seem about equal, if not better, in output compared to the Cree XR-E).

    BTW, I think that 1-2mm height increase is what allows the Edison to work well with Lux-based reflectors (higher die height for better focus and thus no spacing required).
    Streamlight: TL-3 Xenon, Vital Stream Scorpion-FB1, Scorpion LED SSC P4, KeyMate Silver (Nichia CS)
    Nuwai: 2x QIII TWOH (Green and Titanium), TM-313X Ti (QV1J DD 14500)
    Surefire: M2+C2-HA+Detonator, E2D, VG FB1+EXe, VG FB3+E2C+C2
    Vital Gear F2, Huntlight FT01, Jetbeam Jet1 AA and 123A, Fenix E1 (Silver), Luxogen LR5A-3W & LR12 CR2 (SCC P4), Spiderfire LR8, NexTorch Z1, Gerber Infinity Ultra (2x Green), Dae's UV 12LED
    Emergency Kit & Knives Pics - Lights & Knives Pics - Small Knife/Lights

  5. #5
    Flashaholic
    Join Date
    Dec 2002
    Location
    Kettering,OH
    Posts
    78

    Default Re: Edixeon KLC8 versus Cree XR7090 in the Elly

    For what its worth, the Edison is better suited for use with optics. The yellow corona disappears ( I modded my X3 bike light, way brighter than the T bin lux 3 it replaced.)

  6. #6

    Default Re: Edixeon KLC8 versus Cree XR7090 in the Elly

    1. the -neg. pole on the backside(more difficult to install)
    - Why was the negative lead harder to install?
    My mistake!!! I meant +positive ; To have a neutral or a negative on the the back of the led it easier to connect it to the flashlight housing for cooling purposes. otherwise you have to use a Star or a lot of non-electricity conductive glue.

    2. Lower build quality compared to the Cree
    - What specific areas of the LED did you see the Edison as being lower quality than the Cree?
    The finish is rougher and most important ;the Cree has an edge around the led (embedded) I think to prevent side spilling of yellow light

    Once again they will give you a lot of light (more than a Cree) but don't expect the same homogeneous light


    edit1:
    these are the colors (colorshift) you can aspect when using it in a reflector flashlight;


    I also tried the Edison's on a few optics (luxeon and luxeon K2 optics 5,6 an 10 degrees) The yellow was still there but indeed less obvious
    Last edited by kanarie; 02-23-2007 at 06:49 PM.

  7. #7
    Flashaholic*
    Join Date
    Dec 2005
    Location
    socal
    Posts
    1,901

    Default Re: Edixeon KLC8 versus Cree XR7090 in the Elly

    Wow, that's really yellow around the hotspot! Is the picture an accurate representation of how yellow the corona is in person?
    Streamlight: TL-3 Xenon, Vital Stream Scorpion-FB1, Scorpion LED SSC P4, KeyMate Silver (Nichia CS)
    Nuwai: 2x QIII TWOH (Green and Titanium), TM-313X Ti (QV1J DD 14500)
    Surefire: M2+C2-HA+Detonator, E2D, VG FB1+EXe, VG FB3+E2C+C2
    Vital Gear F2, Huntlight FT01, Jetbeam Jet1 AA and 123A, Fenix E1 (Silver), Luxogen LR5A-3W & LR12 CR2 (SCC P4), Spiderfire LR8, NexTorch Z1, Gerber Infinity Ultra (2x Green), Dae's UV 12LED
    Emergency Kit & Knives Pics - Lights & Knives Pics - Small Knife/Lights

  8. #8

    Default Re: Edixeon KLC8 versus Cree XR7090 in the Elly

    Wow, that's really yellow around the hotspot! Is the picture an accurate representation of how yellow the corona is in person?
    Yes, this picture is selected because it shows how it will look in true life!

    f.e. on a focused Mag. the yellow corona will be smaller but the colorshift from the center to the corner will be more dramatic..

  9. #9
    Flashaholic* nanotech17's Avatar
    Join Date
    Jul 2006
    Location
    N 03°13.884° / E 101°29.329°
    Posts
    2,151

    Default Re: Edixeon KLC8 versus Cree XR7090 in the Elly

    i put mine in my andslite torch running with 3x2700 sanyo nimh .
    the yellow spill beam is there but it was brighter compare to the LuxIII.
    Runs cooler,might purchase more for few more mod.
    No complains from me as long this thing is BRIGHT
