Catalog of Discontinued Surefire Flashlights

[ElectronGuru]

Lets build a catalog showing each model flashlight that SF used to build but no longer does. I'll start off with a few, but suggestions (and links) are most welcome. For the purposes of this list, entries are limited to models of flashlights. This should compliment the excellent rare/unusual thread and not list special colors or commemorative versions based on an existing model of light. I'll try and add photos when possible.

Original handheld

6C (superseded by the 6P)

Classic P-Series

3P (superseded by the E1, and then the E1e)

6P

9P

6PS
6PSN
12PM (never sold as, but sometimes referred to as 12P)

Classic Centurion

M2 (small bezel, round bottom M2 became the flat bottom C2, M2 adopted a larger shock bezel)

Classic Z-Series "CombatLights"

6Z (superseded by the Z2)

7Z

9Z (superseded by the also discontinued Z3)

9ZT (9Z+turbohead)

12ZM (never sold as, but sometimes referred to as 12Z)
Z3

D-Series

D2

D3

Classic Rechargeable handhelds

3R
6R
[7Z listed under Z-Series]
8X
9N (and it's R90, and dedicated charging systems)

Classic Extended Range TurboHead

6PT (and associated TurboHead Kit T1)
6RT (and associated TurboHead Kit T4)
9PT (and associated TurboHead Kit T2)
8XT (and associated TurboHead Kit T5)
9NT (and associated TurboHead Kit T3)

E-Series

E1
E2
E2o (aka E2O) "Outdoorsman" NB: MN02 Lamp Assembly also discontinued
E1L (KL1 bezel)

E2L (KL1 bezel)

E1L (single-level KX1 bezel)
E2L (single-level KX2 bezel)

L-Series

L2 (superseded by the LX2)

L6 (KL6 bezel)
L7 (KL7 bezel)

KL-Series Bezels

KL1
KL2
KL3
KL6
KL7

BatonLight Series

3BL
3BL1
3BL2
6BL
6BL1
6BL2

ShieldLights

6S25
8S
9S25
6SL
9SL
9SLA01

WeaponLights (general)

[Classic models too numerous to list]
P-Series "Nitrolon"
W-Series "Military"
M-Series "Millennium"
X200 Series (X200A & X200B) (superseded by the X300 & X400)
M98 Series
M500B Series (includes M500B, M510B, M511B)
L120M Leopard-Light Lamp Module

9 Volt Shot-Gun Weaponlights (91x-Series)

Classic IR Illuminators

3DL (superseded by the M1)

Battery Carriers

12B (aka Hurricane Case)

Special Editions

Model B1 "The Beast"
M2-ST (Strider)
C2-EM (Emerson)
6P-USA (classic)
6P-USA (hex)

C2-CJ (camo jungle)
E1e-Bk-HA

E1w Winelight

E2w Winelight

E2e-CJ (camo jungle)

References

1996 Illumination Tools Catalog
1997 Tactical Products Catalog
2001 Illumination Tools Pricelist
2001 WeaponLight Pricelist
2001 Millenium WeaponLight Brochure
2002 Illumination Tools Catalog
2002 WeaponLight Catalog
2003 Illumination Tools Catalog
2004 Illumination Tools Catalog
2005 Illumination Tools Catalog
2005 Tactical Products Catalog
2006 Illumination Tools Catalog
2006 Tactical Products Catalog
2007 Illumination Tools Catalog
2007 Tactical Products Catalog
2008 Tactical Catalog
2009 Tactical Catalog
2010 Products Catalog
2011 Products Catalog
2012 Products Catalog

[angelofwar]

-6R
-7Z
-3BL
-918FA
-E20
-Surefire "Six" (the ORIGINAL SF which would now be the 6P...This may also be the 6C EG refers too in his above post???)

Too name a few...good idea though...this will be the flashlight museum 20 years down the road...and is an excellent place to record such information! Nice idea electronguru!

Added...

-L6
-L7
-The "Beast", if that counts...

[B737Driver]

E1-HA
E1-GM

E2-HA
E2-GM

[alflys2]

3R
3DL

[Size15's]

Note that SureFire.com is not a thorough indication of SureFire no longer offering the product. It would be great to get word directly from SureFire else label it has "presumed" or something.

The M98 Series is not the same as the Leopard-light (which may not have been discontinued BTW). There was never an "M98X" (if "X" is meant as generic then it should be "x")

The 12P/12Z are the very early name for the 12PM/12ZM - NOT versions without the TurboHead.

The L5 has been replaced by the "L5A", although this is a CPF term, it's more accurate to say the KL5 has been replaced by the KL5A.

One would need to check whether the same is 'true' for the KL4 - replaced by the KL4A or whether it was an inline change like the U2 (to U2A)

Have the BatonLights actually been discontinued?

The E2o Outdoorsman has been discontinued.

KL1, KL2, KL4, KL5, KL6, KL7 bezels have been discontinued I believe.
Not sure about the KL3 though.

The X200A and X200B have been replaced by the X300.

BTW, the Hurricane Case was model 12B

[angelofwar]

The KX3 has replaced the KL3 as far as I can tell, as the KL3's have been slowly dissappearing on several websites, showing out-of stock or discontinued/no longer available, especially the colored ones.

Correct, Al...according to SF the Leopard Light is a mounted M4 with a tape switch (so it can pull double duty as weapon mounted/hand-held), as opposed to the M98X series with the integrated mounts, which have been discontinued according to several of SF's biggest on-line dealers, and no longer appears in the listing at the back of there catalogs. They (accidentally???) mis-id'ed the leopard light in there 2005 tactical catalog, as they picture an M98X, but describe it on there website in there low-light sniping article as the M4 w/ tape switch and scope rings. Or maybe the Leopard Light (in 2005) was an M98X with scope rings and was later replaced with the M4 when the M98X's were discontinued???

[Size15's]

There is no such thing as "M98X", if neccessary, which it isn't, it should be M98x.
The Leopard Lights are essentially special order and in some cases where there is Picatinny Rail on top of the Scope/Scope mount then it is possible for the Leopard to be based on the M98. The main difference is that it'll have a longer remote switch than the standard XM07 7" remote.

The original Leopard uses a different body to the 12PM - it has cooling thins and has no need for the TurboHead adapter collar. It was Lamp Module L120M if memory serves.
They then moved to the M4 with remote.

Like with the M500 Series, the 'big guns' models "B" and M98 have been removed from the listing but can still be created using the various Lamp Modules and Module Kits etc.

[angelofwar]

Removed...

[carrot]

E20 should actually be E2O Outdoorsman.

Haven't heard about the 6PN in years, probably discontinued.

I believe the Z3 is discontinued.

Are we counting L4 and U2? They have been replaced by variants, L4A and U2A.

[angelofwar]

Ahhh...the Z3...nice catch, Carrot. Yeah, I put the 0 in instead of an O...it was getting late last night. It came stock with the MN02 for the longer runtime, hence the tag "Outdoorsman" as opposed to the "tactical", higher out-put E2E, but became "obsolete" when the E2L came out...

[Yavox]

4-flats A2 Aviator?

[Tempest UK]

Are we counting L4 and U2? They have been replaced by variants, L4A and U2A.

I think they're different. They're not replacements, as such. The L4 is still the L4 and the U2 is still the U2 (as per the website), even though they might be called otherwise on CPF.

The U2A is simply an inline update of the U2 with a newer emitter. This isn't a new practice.

More questionable is the "L4A". The model remains the same - it's simply the "KL4A" head that has changed. The same is true for the KL5A - the model remains the L5 even though the head has changed.

I would imagine that the 6PN is still available, as it's not a different model as such, but rather an existing one that has been tested in a certain way.

4-flats A2 Aviator?

As with the "L4A" and U2A, I don't think this qualifies as a discontinued model, as the model itself (A2) still exists. Everything else about the light remains the same - only a fairly minor cosmetic change was made.

A more interesting question, I think, is that of why certain models were discontinued. Of course, a lot of the answer will boil down to decreasing demand, new technologies and redundancies emerging in the product range.

The 3P, for example, didn't offer much in comparison the the E1 and later E1e. Bigger size, unimpressive output...I'm not surprised it disappeared. It also didn't have the flexibility that may have allowed the 6P to remain despite the emergence of the Executive series.


Regards,
Tempest

[ElectronGuru]

Are we counting L4 and U2? They have been replaced by variants, L4A and U2A.

My parts list shows U2-BK-WH (DIGITAL F/L, 5W WH LED, BLACK) as being available, so this is an improved version of the same model, not a new model.

4-flats A2 Aviator?

The C2 used to come with 2 flats and third rounded side. It was and still is a C2.

For the purposes of this thread, the test is:

1) was it in production such that you could buy it and it had a model number for doing so?
2) was any change significant enough that SF gave it a new model number?
3) is the new model number now available and the old model number, not?

I would imagine that the 6PN is still available, as it's not a different model as such, but rather an existing one that has been tested in a certain way.

Its always been an obscure model, but it does show on my 2010 list:

6PN-BK (FL, BLACK ANO, MOMNTRY TLCP SW, 6V, 1.25 BEZ, 30M SUBMERSIBLE)

The 3P, for example, didn't offer much in comparison the the E1 and later E1e. Bigger size, unimpressive output...I'm not surprised it disappeared. It also didn't have the flexibility that may have allowed the 6P to remain despite the emergence of the Executive series.

In factory configuration, it offers no advantage. With P60 module capability, its value in the upgrade market has soared.

[Size15's]

Is the 6PS or indeed the 6PSN on your list?

What about the Shield Lights?

[ElectronGuru]

Shield Lights = nothing with the word shield apart from (HELLFIGHTER SHIELD BARREL MOUNT)


6PS = no
6PSN = no

Shock 6P eh, I would love to see that!


But just to be clear, my list is not the end of the line. Z17 lens kits, for example, are not on the list either and I am able to order them.

[Size15's]

The 6PS is simply a 6P body and TailCap with old-school Z32 shock isolated bezel

SureFire Shield Lights models 6S25, 8S, and 9S25

If you're wanting to gather all the models there are BatonLights 3BL1, 3BL2, 6BL1 and 6BL2 as well.

The 8X and 9N rechargeables have been discontinued.

The 6PT, 6RT, 9PT, 8XT & 9NT Extended Range TurboHead models (and their associated TurboHead Kits T1, T2, T3, T4 & T5) have been discontinued.

Another set of discontinued SureFires are the P-Series Nitrolon, W-Series Military and M-Series Millennium Handgun WeaponLights.

The M500 Series "B" models have been discontinued.

[ElectronGuru]

Another set of discontinued SureFires are the P-Series Nitrolon, W-Series Military and M-Series Millennium Handgun WeaponLights.

Do you happen to have specific model numbers for these?

The 6PS is simply a 6P body and TailCap with old-school Z32 shock isolated bezel

Guess that would make this a G2S

List updated

[carrot]

Except the new, finless heads are hideous IMHO

[Size15's]

I've started to put the list under headings...

Original handheld:
6C (superseded by the 6P)

Classic P-Series
3P (superseded by the E1, and then the E1e)
6PS
6PSN
12PM (never sold as, but sometimes referred to as 12P)

D-Series
D2
D3

Classic Z-Series "CombatLights"
6Z (superseded by the Z2)
7Z
9Z (superseded by the also discontinued Z3)
12ZM (never sold as, but sometimes referred to as 12Z)
Z3

Classic Rechargeable handhelds:
3R
6R
[7Z listed under Z-Series]
8X
9N (and it's R90, and dedicated charging systems)

Classic Extended Range TurboHead Models
6PT (and associated TurboHead Kit T1)
6RT (and associated TurboHead Kit T4)
9PT (and associated TurboHead Kit T2)
8XT (and associated TurboHead Kit T5)
9NT (and associated TurboHead Kit T3)

BatonLight Series
3BL
3BL1
3BL2
6BL
6BL1
6BL2

ShieldLights
6S25
8S
9S25
6SL
9SL
9SLA01

Classic IR Illuminators
3DL (superseded by the M1)
L46 IR Lamp Module [may not be discontinued?]

Battery Carriers
12B (aka Hurricane Case)

Handgun WeaponLights
Classic models too numerous to list.
P-Series "Nitrolon"
W-Series "Military"
M-Series "Millennium"
X200 Series (X200A & X200B) (superseded by the X300 & X400)

E-Series
E1
E2
E2o (aka E2O) "Outdoorsman" NB: MN02 Lamp Assembly also discontinued
E1w (aka WineLight I)
E2w (aka WineLight II)
E1L (KL1 bezel)
E2L (KL1 bezel)
E1L (single-level KX1 bezel)
E2L (single-level KX2 bezel)

L-Series
L2 (superseded by the LX2)
L6 (KL6 bezel)
L7 (KL7 bezel)

KL-Series Bezels
KL1
KL2
KL3
KL6
KL7

WeaponLights
Classic WeaponLight models too numerous to list
M98 Series
M5xxB Series (includes M500B, M510B, M511B, M520B, M560B, M570B)
"Leopard Light" & associated L120M Leopard-Light Lamp Module (includes models 1251-06, 1251-07, 1251-10, 1252-06, 1252-10 & 1265M)

Model B1 "The Beast"

[Size15's]

Do you happen to have specific model numbers for these [handgun WeaponLights]?

There must be dozens
WeaponLights, especially the Classic-Series are not something I think we should attempt to list here. Very complicated. So many options, many likely have never actually been made to order)

[alflys2]

8N looks like 9N but only center bulb.

[Size15's]

8N looks like 9N but only center bulb.

Do you have any photos of this model please? I don't recall ever having heard of it
I always though it was internet confusion (tpyo) due to there being the 8X, 8AX & 8NX.
I've seen people refer to their 8NX as '8N'...

[JNewell]

Dan, when you say "smooth bezel," do you mean without the fine vertical (axial) lines?

The C2 used to come with 2 flats and third rounded side. It was and still is a C2.

I have one of those...#A00279. Came in a plastic clamshell pack.

[Size15's]

Dan, when you say "smooth bezel," do you mean without the fine vertical (axial) lines?

Because there have been a few versions of the 'standard' bezel before the familiar current version with it's hexagonal anti-roll feature, I don't feel the difference is significant enough to count older versions of the 6P (for example) as discontinued because they aren't distinct models.

[Tempest UK]

It would be impressive to include pictures of all these discontinued models. Perhaps with a short blurb about each. Then it would be a catalog

Regards,
Tempest

[JNewell]

Because there have been a few versions of the 'standard' bezel before the familiar current version with it's hexagonal anti-roll feature, I don't feel the difference is significant enough to count older versions of the 6P (for example) as discontinued because they aren't distinct models.

Fair enough. Trying to figure out what Dan's looking for pictures of. I have a black 3P and an original "gunmetal" 6P (much lighter than current ano) but IIRC both have the vertical grip cuts. I think my 6Z originally had a perfectly smooth bezel. These are all from the '90s, well before the hex bezel with Pyrex window.

[Size15's]

The 1996 catalog features plenty of them!

[JNewell]

It would be impressive to include pictures of all these discontinued models. Perhaps with a short blurb about each. Then it would be a catalog

Regards,
Tempest

Or maybe an (eek) Wiki...

[Tempest UK]

I have a black 3P and an original "gunmetal" 6P (much lighter than current ano) but IIRC both have the vertical grip cuts. I think my 6Z originally had a perfectly smooth bezel. These are all from the '90s, well before the hex bezel with Pyrex window.

All of my Laser Products 3P, 6P and 9P lights have those "vertical cuts", but none of my 6Zs or 7Zs do - they're all smooth.

Regards,
Tempest

[ElectronGuru]

I've started to put the list under headings...

Wow, OP updated! Also great would be the date range a given model was available (ie, 1994-2002)

There must be dozens

Understood

It would be impressive to include pictures of all these discontinued models. Perhaps with a short blurb about each. Then it would be a catalog

Yup, models by family, date range, plus example photos of each

Fair enough. Trying to figure out what Dan's looking for pictures of.

If you have a good color image of any of these models in the standard color, please post or PM me a link.

For easy comparisons, I would like roughly the following sizes:

600 pixels wide - 1 cell (3P, etc)
700 pixels wide - 2 cell (6P, etc)
800 pixels wide - 3 cell (9P, etc)


example 2 cell




example 3 cell

The 1996 catalog features plenty of them!

I have a scanner (and maybe a camera) but no catalog. Perhaps we can do one volunteer at a time.

All of my Laser Products 3P, 6P and 9P lights have those "vertical cuts", but none of my 6Zs or 7Zs do - they're all smooth.

That matches what I've seen. P's have bezel grip, Z's do not.
