Thread: On Determining Actual versus Claimed Capacity of NiMH Cells

  1. #1
    Flashaholic* Bones's Avatar
    Join Date
    Feb 2007
    Location
    Foothills Country
    Posts
    991

    Default On Determining Actual versus Claimed Capacity of NiMH Cells

    Insofar as I'm aware, the IEC approved protocol for determined the capacity of an NiMH cell consists of the following:
    • Charge at rate equal to 1/10th of the cell's rated capacity for 16 hours.
    • Allow the cell to rest for one hour.
    • Discharge at a rate equal to 1/5th of the cell's rated capacity down to 1.0 volts.

    The 16 hour charge at 1/10 of a cell's rated capacity is often referred to as a 'standard' charge.

    As demonstrated by this image provided by forum member Quension, the IEC protocol may even be referenced in a cell's capacity statement:



    Owner's of the Powerex MH-C9000 will note its Break-in mode approximates the IEC protocol.

    While other capacity measurement methodologies can be better suited for determining a cell's actual performance under specific conditions, those methodologies are irrelevant insofar as determining a cell's actual versus its rated capacity.
    I don't know why we are here, but I'm pretty sure that it is not in order to enjoy ourselves

  2. #2
    *Flashaholic* Mr Happy's Avatar
    Join Date
    Nov 2007
    Location
    Southern California
    Posts
    5,390

    Default Re: On Determining Actual versus Claimed Capacity of NiMH Cells

    Indeed. As I recall, it is also advised to do several of the standard charge/discharge cycles before taking the actual capacity measurement.

  3. #3
    Flashaholic* TorchBoy's Avatar
    Join Date
    Jan 2007
    Location
    New Zealand
    Posts
    4,495

    Default Re: On Determining Actual versus Claimed Capacity of NiMH Cells

    The only times I've done a couple of (39 hour) break in cycles in a row on my MH-C9000 the second round came out with a lower capacity. That's not quite what I was expecting.
    No, a torch does not always mean flames.
    Ian.
    LED Driver List - now database driven and with new search features.

  4. #4
    Flashaholic* NutSAK's Avatar
    Join Date
    Jun 2006
    Location
    3rd stone from the sun
    Posts
    1,200

    Default Re: On Determining Actual versus Claimed Capacity of NiMH Cells

    That's the protocol I'm aware of also.

    I believe it's the same method used for determining NiCd capacity also, is it not? I'm testing a Dewalt DW9099 NiCd battery with my Accucel-6 using approximately that method at the moment.
    - Terry

  5. #5

    Default Re: On Determining Actual versus Claimed Capacity of NiMH Cells

    Yep, that's the standard.

    For our purposes, discharging the cell near our intended discharge rate is going to provide more useful numbers for ranking a given set of cells against each other.

    In particular, many of us run our cells at closer to 1C.

    It would be interesting to see comparisons for cells at that rate. I think we'd probably find that the favorite cells still perform well.
    EDC E1B, Tigerlight w/LED dropin for when I need more light. Love my new Zebralight H30 for floody tasks and my Quark Mini123 for being awesomely small and bright.

  6. #6
    Flashaholic* Russel's Avatar
    Join Date
    Jan 2009
    Location
    California
    Posts
    583

    Default Re: On Determining Actual versus Claimed Capacity of NiMH Cells

    One other aspect of the IEC standard is ambient temperature. While it isn't critical for the purpose of checking capacity of your battery inventory, it might be a good idea to make a note of the ambient temperature during the test. Especially if you see extreme seasonal temperature changes.
