Thread: Improving the DIY integrating sphere

  1. #1

    Default Improving the DIY integrating sphere

    I am truly amazed at the time and effort that many here have put into building integrating spheres. The cooperation seen in the past amongst the community in helping one another with calibration and builds has been one of CPFs high points. There has been a great deal of effort expended on deciding how best to build these spheres but I have found it intriguing that one of the most important aspects of an IS has completely been ignored. Sure there have been a few here and there that have made mention of the need for a proper coating but I know of no one yet that has actually done it. I know people here care about having as accurate a device as is possible so the only thing I can figure is that people just don't see the importance. Well hopefully we can change that.

    If you do any amount of research into IS you will find how much they stress the importance of a good coating. Without the coating your IS is more of a S. than an IS. There are two main qualities you want in the coating. Diffuse reflectivity and it needs to reflect as much of the spectrum as possible. A standard flat white paint from the hardware store may fill the need for diffuse but it is doubtful it will faithfully reflect the spectrum of the light source. That would lead to incorrect readings.

    Spectralon is the industry standard for coatings as it is an exceeding good diffuse reflector over a wide spectrum range. It is also exceedingly expensive and out of reach to the DIYer. So what to do?

    In my research I found this article that mentions that barium sulfate powder alone on a surface actually performed better than Spectralon in the 425nm-600nm range which just so happens to be the sweet-spot for what we deal with here. Of course they rightly saw a need for a binder agent as just applying powder to a surface without having something to hold it all together and to the surface is not a good idea. So they mixed it in with a white latex paint. The problem is that the performance decreases as paint is added. This got me to thinking about the need to have the bare powder face out to get the best performance so I started to do a little experimenting. So far the best binder I have found is a white latex paint but I don't mix the BS into the paint but rather paint the surface and then while it is still wet dust it so that the powder adheres. This leaves a very flat(as in sheen) and diffuse reflecting surface. Perfect for an IS.

    To show the difference in performance between the bare foam as is used in most of the DIY spheres I made a little demo and posted it over at my youtube account. I invite you to take a look at just what a difference it can make. Sorry that the sound seems out of step with the video. I have no idea how to fix that.

    And here's the best part. It's incredibly cheap! Here is a link to a pound of the powder for only $6 plus shipping. This is an absolute must have in my opinion if you want your integrating sphere to be a true tool. So get cracking on those spheres.
    Last edited by saabluster; 04-11-2011 at 03:26 AM.

  2. #2
    Flashaholic* angelofwar's Avatar
    Join Date
    Nov 2007
    Location
    South Carolina
    Posts
    3,336

    Default Re: Improving the DIY integrating sphere

    Not to mention, there's an App to put a Lux-Meter on your Ipod Touch or IPhone...may be able to use this in the shoe-box method? Not sure how accurate it is, but it will definitely tell you which of the lights you have are brighter.

  3. #3
    Flashaholic* Glenn7's Avatar
    Join Date
    Jul 2006
    Location
    Tasmania, Australia (the butt end of oz)
    Posts
    1,569

    Default Re: Improving the DIY integrating sphere

    Mike,
    I am so glad you did this as I have never really liked those Styrofoam sphere readings mostly because any photos I have seen of people's set ups show the light going/shining through onto the wall behind the sphere and that is light lost - even more noticeable with throwy lights and thats why some lights I know have not been given good ratings.

  4. #4

    Default Re: Improving the DIY integrating sphere

    Quote Originally Posted by angelofwar View Post
    Not to mention, there's an App to put a Lux-Meter on your Ipod Touch or IPhone...may be able to use this in the shoe-box method? Not sure how accurate it is, but it will definitely tell you which of the lights you have are brighter.
    Well I suppose it might be better than your eye but anyone who wants their measurements to be taken seriously should avoid using the iphone. It might tell you which one is brighter and then it may not especially when linked to a box. There is a reason they don't make integrating boxes.

    Quote Originally Posted by Glenn7 View Post
    Mike,
    I am so glad you did this as I have never really liked those Styrofoam sphere readings mostly because any photos I have seen of people's set ups show the light going/shining through onto the wall behind the sphere and that is light lost - even more noticeable with throwy lights and thats why some lights I know have not been given good ratings.
    Well don't get too caught up on the fact that some light escapes out the back. It does that with my setup as well although it is attenuated some. It would have in the test done in the link provided as well. A little light leakage will not change the fact that the powder is a diffuse reflector and faithfully reflects the spectrum. It does mean however that every effort should be made to have the layer of barium sulfate be uniform as possible. Otherwise it will make a little bit of difference in the consistency of performance between lights with very different beams.
    Last edited by saabluster; 04-11-2011 at 01:54 PM.

  5. #5
    Flashaholic* angelofwar's Avatar
    Join Date
    Nov 2007
    Location
    South Carolina
    Posts
    3,336

    Default Re: Improving the DIY integrating sphere

    Yeah, I just got it for a quick reference, and don't plan to take "serious" lux readings...just thought I'd put it out there for others who may be interested

  6. #6

    Default Re: Improving the DIY integrating sphere

    Quote Originally Posted by angelofwar View Post
    Yeah, I just got it for a quick reference, and don't plan to take "serious" lux readings...just thought I'd put it out there for others who may be interested
    I have an iPhone so I looked it up. It doesn't get very good reviews. I'd do it if there was a free version but I'm not paying for it.

  7. #7

    Default

    Quote Originally Posted by saabluster View Post
    I have an iPhone so I looked it up. It doesn't get very good reviews. I'd do it if there was a free version but I'm not paying for it.
    The best one out there for iPhone is called Pocket Light Meter. Very good UI -- as in, there almost isn't one, it just works. I don't have a "real" light meter to compare absolute numbers, but it seems to be at least monotonic (brighter things measure higher) and consistent (same thing measured twice gives the same answer to within a few percent).

    Please tell me I'm not the only person who's actually tried to get useful measurements from a cell phone and an Integrating Toilet Bowl.

  8. #8
    Flashaholic* QtrHorse's Avatar
    Join Date
    May 2008
    Location
    Texas
    Posts
    1,159

    Default Re: Improving the DIY integrating sphere

    That is a very interesting video. I knew the coating was important but I did not think it would make that much of a difference.

  9. #9

    Default Re: Improving the DIY integrating sphere

    I can't believe this thread hasn't gotten more response. I mean the video is a clear demonstration even without the lux meter it's just plain obvious what kind of impact the coating had. I would've guessed that all the DIY-sphere-makers would be congratulating you on the discovery..

  10. #10

    Default Re: Improving the DIY integrating sphere

    Interesting, I will probably build a new sphere with barium sulfate coating. Only problem is that I can find only 25kg or bigger packaging for sale locally

    On the other hand I would like to see cross test between calibrated bare styrofoam sphere and calibrated barium sulfate coated sphere.

    I did some tests with laser pointers and I was surprised how uniformly lit was the inside of the sphere. So if the styrofoam is diffuse enough for a laser it should be diffuse enough for flaslights.


  11. #11

    Default Re: Improving the DIY integrating sphere

    Quote Originally Posted by jirik_cz View Post
    Interesting, I will probably build a new sphere with barium sulfate coating. Only problem is that I can find only 25kg or bigger packaging for sale locally

    On the other hand I would like to see cross test between calibrated bare styrofoam sphere and calibrated barium sulfate coated sphere.

    I did some tests with laser pointers and I was surprised how uniformly lit was the inside of the sphere. So if the styrofoam is diffuse enough for a laser it should be diffuse enough for flaslights.
    Using a laser is actually a really good idea to figure out how well the sphere works. Just remember that whether or not it is uniformly lit or not should be based on instrumented measurements not ones eyes. If the bare foam is in actuality a good performer than you should be able to move the aim of the laser around inside the sphere and have the light meter read the same. Have you tried that yet? What were the results?

    But remember too that the diffusion is only half the issue. You still want a coating that faithfully reflects the spectrum.
    Last edited by saabluster; 04-14-2011 at 11:41 AM.

  12. #12

    Default Re: Improving the DIY integrating sphere

    Quote Originally Posted by saeckereier View Post
    I can't believe this thread hasn't gotten more response. I mean the video is a clear demonstration even without the lux meter it's just plain obvious what kind of impact the coating had. I would've guessed that all the DIY-sphere-makers would be congratulating you on the discovery..
    Thanks. It may be that some have not seen it since I did not put it in the same forum as all the threads about IS(LED flashlights). I just don't feel the IS is so narrow in focus as to belong in that forum. Many people start their threads there because there is more traffic over there than there is here. Still undoubtedly many of them have read this thread. I don't require congratulations from them though. Hopefully at least some people will see the importance and make the needed changes.

  13. #13

    Default Re: Improving the DIY integrating sphere

    I certainly did not know of this thread until tonight. Very interesting video. But the differences in reflectivity of white styrofoam versus a coating of barium sulfate over white satin finish interior latex paint is not conclusive that the "calibrated" readings of the home made spheres versus the real integration spheres is that far off because its more reflective. Nor is Barium Sulfate by itself with a sweet spot of 425 to 600 nM the ultimate answer. Wbp and I were doing work with his very expensive spectral radiometer looking at the color spectrum of various LED sources. They certainly go well below 600nM especially the warm ones. Incandescents of course have lots of lot down into the red well below this range. A good integration sphere is supposed to reflect the entire spectrum of white light. I remember wbp was looking into this between the real sphere that he had and the styrofoam sphere, but to be honest, I don't remember the exact results. We were using various light sources that we had, what we didn't have was something to give a broad spectrum of "daylight" to compare the two. Point is there is nothing to say that the white reflection of a styrofoam sphere is any worse than the Spectralon used in real spheres as far as the color spectrum that its reflecting.

    I had personally tried testing various individual colored lights in the professional sphere I had at work versus the home made spheres I put together, I had UV, blue, green and red. Now I wasn't using a $9K spectral radiometer at home to compare the 2, I was using the CA813 meter with photopic filter. Point is I got pretty close comparitive results. I had a lower cost meter and when I saw that the UV light source was reading more than the green one I knew something was wrong there. The UV light source should not show up through the photopic filter as visible light. It had about 0.1 lumens of visible light spectrum in the real sphere system at work and that's about all it had in my home made system with the CA 813 meter. But with the CA 811 meter it read about 5 lumens. I sent that meter back. The testing of the various color lights that I did was not conclusive either but it gave some level of confidence.

    As to the question you raise about the foam being too reflective, creating a calibration "constant" number in the home made sphere by cross checking it with a light in the real sphere and then testing various lights I was able to get less than 5% error, or 95% accuracy. Going from a floody light to a thrower light in the professional sphere and then testing it at home in the stryrofoam sphere using the same "constant" number, I was able to get numbers that were within 95% or better agreement at home to the professional sphere. So correcting for the higher reflectivity in the styrofoam sphere just meant having a larger correction number. I think the key was to have a good baffle system to block direct light from entering the sensor port.

    It would be very interesting to run a test of 2 sphere systems with the same sets of lights, one with the barium sulfate (since the cost of Spectralon is very prohibitive) and the other as is with just the original styrofoam, and after calibrating them with a known light source of a floody type, and coming up with a calibration "constant" number for each system (that number won't be the same for each sphere) to see if they both read the same lumens using the same correction constant for each system previously determined with a "thrower" type light. I would expect the pure foam unit would have higher divide by constant number than that of the barium sulfate coated unit, but that doesn't mean that it will work better when going from a soft flood type light to the thrower light. It might, it would definitely be with testing. Some one would have to do this with the exact same meter in two identical sized spheres with identical baffle systems in them but one with the barium sulfate coating.

    Then after all of that is done, testing it with blue, green, red, Incan versus cool white LEDs in each system to see if the readings are the same or not, that would be a great test. Of course this is a lot of work, and that's part of the problem. Wbp and I at the time simply concluded that the plain styrofoam sphere was close enough.

  14. #14

    Default Re: Improving the DIY integrating sphere

    Quote Originally Posted by MrGman View Post
    I certainly did not know of this thread until tonight. Very interesting video. But the differences in reflectivity of white styrofoam versus a coating of barium sulfate over white satin finish interior latex paint is not conclusive that the "calibrated" readings of the home made spheres versus the real integration spheres is that far off because its more reflective.
    No the test was not the be-all-end-all. It does dramatically show the inherent problems with bare foam and that being specular reflectance. This is the main problem I see with the bare foam. The surface must come as close to a diffuse reflector as possible and the bare barium sulfate blows the bare foam away in that regard. It is this quality or lack thereof that is the major contributor to lack of consistency between lights with a different beam shape.

    Quote Originally Posted by MrGman View Post
    Nor is Barium Sulfate by itself with a sweet spot of 425 to 600 nM the ultimate answer. Wbp and I were doing work with his very expensive spectral radiometer looking at the color spectrum of various LED sources. They certainly go well below 600nM especially the warm ones. Incandescents of course have lots of lot down into the red well below this range. A good integration sphere is supposed to reflect the entire spectrum of white light.
    Keep in mind that what we care about is what we see. The closer you get into the infrared the less and less it matters. When I said "sweet spot" I was referring to the fact that bare barium sulfate(heretofore indicated as BS) is better than the industry standard across that region not that it just drops straight off either side of the range mentioned. In fact if you look at the chart you will see that at the very edge of a human's ability to see in the infrared the bare BS is still 97.5% the reflectance of the Spectralon. More weight however should be give to the part of the spectrum that we see more in and in that area the BS is superior.

    For the price I'd say BS is the ultimate answer.


    Quote Originally Posted by MrGman View Post
    I remember wbp was looking into this between the real sphere that he had and the styrofoam sphere, but to be honest, I don't remember the exact results. We were using various light sources that we had, what we didn't have was something to give a broad spectrum of "daylight" to compare the two. Point is there is nothing to say that the white reflection of a styrofoam sphere is any worse than the Spectralon used in real spheres as far as the color spectrum that its reflecting.
    It is hard finding info that is not buried in purchasable-only publications.



    Quote Originally Posted by MrGman View Post
    As to the question you raise about the foam being too reflective, creating a calibration "constant" number in the home made sphere by cross checking it with a light in the real sphere and then testing various lights I was able to get less than 5% error, or 95% accuracy. Going from a floody light to a thrower light in the professional sphere and then testing it at home in the stryrofoam sphere using the same "constant" number, I was able to get numbers that were within 95% or better agreement at home to the professional sphere. So correcting for the higher reflectivity in the styrofoam sphere just meant having a larger correction number. I think the key was to have a good baffle system to block direct light from entering the sensor port.
    Yes you may have a baffle to block direct exposure but the first order reflections can bypass that baffle. The best test of whether or not the diffuse coating matters should be borne out testing with a laser and moving it around. Here is my point though. Why use a band-aid instead of just building it correctly? I am setting up my sphere so that absolutely no math has to be done. What the meter reads is what it is. I say that with one caveat. I may be setting up a system whereby I insert the light into the port and then use a separate light to measure the lost lumens to the inserted object. So I might have to do some very basic math but only to have extremely accurate measurements.

    Quote Originally Posted by MrGman View Post
    It would be very interesting to run a test of 2 sphere systems with the same sets of lights, one with the barium sulfate (since the cost of Spectralon is very prohibitive) and the other as is with just the original styrofoam, and after calibrating them with a known light source of a floody type, and coming up with a calibration "constant" number for each system (that number won't be the same for each sphere) to see if they both read the same lumens using the same correction constant for each system previously determined with a "thrower" type light. I would expect the pure foam unit would have higher divide by constant number than that of the barium sulfate coated unit, but that doesn't mean that it will work better when going from a soft flood type light to the thrower light. It might, it would definitely be with testing. Some one would have to do this with the exact same meter in two identical sized spheres with identical baffle systems in them but one with the barium sulfate coating.

    Then after all of that is done, testing it with blue, green, red, Incan versus cool white LEDs in each system to see if the readings are the same or not, that would be a great test. Of course this is a lot of work, and that's part of the problem. Wbp and I at the time simply concluded that the plain styrofoam sphere was close enough.
    I haven't coated my sphere yet so I can do some tests but like you I am very busy so don't necessarily have the time to do the full test before I need my sphere done. I will see what I can do.
    Last edited by saabluster; 04-18-2011 at 11:57 AM.

  15. #15

    Default Re: Improving the DIY integrating sphere

    This is all good to know, and will be very interesting to see what you find out. I know that there are businesses that do test services for a fee. Last time we checked into it the cost was around $250.00 per sample. I would say that having at least 2 lights tested as standardized references would be a good start. Good Luck.

  16. #16

    Default Re: Improving the DIY integrating sphere

    Quote Originally Posted by saabluster View Post
    If the bare foam is in actuality a good performer than you should be able to move the aim of the laser around inside the sphere and have the light meter read the same. Have you tried that yet? What were the results?
    I've tried that, but my cheap DX lasers have very unstable output so I can not get proper results.

  17. #17

    Default Re: Improving the DIY integrating sphere

    to have a good stable laser do a test inside the surface of a foam sphere and see if the readings are fairly constant would be very interesting. Having seen the inside of the foam spheres I would concede right off the bat that they are not all that smooth in texture to give a consistent output reflection for a true pin point light source. There are tiny little recesses in the foam sphere. It would be interesting to get one of these really good focusing small flashlights that have a very tight beam and do the same test, moving it all around and see if the reading remains constant or not.

  18. #18
    Flashaholic* Got Lumens?'s Avatar
    Join Date
    Mar 2011
    Location
    Champlain Valley
    Posts
    1,973

    Default Re: Improving the DIY integrating sphere

    Quote Originally Posted by saabluster View Post
    I haven't coated my sphere yet so I can do some tests but like you I am very busy so don't necessarily have the time to do the full test before I need my sphere done. I will see what I can do.
    Saabluster, I would suggest going the course you are with one deviation. That would be to do the first test on your unmodified(non-BS coated) IS with a couple of known sources, one floody one spot? Then as time permits finish the unpgrade and retest. The results should be almost identical to doing two consecutive tests with identical spheres.
    GL
    Last edited by Got Lumens?; 04-18-2011 at 01:33 PM.

  19. #19

    Default Re: Improving the DIY integrating sphere

    Quote Originally Posted by Got Lumens? View Post
    Saabluster, I would suggest going the course you are with one deviation. That would be to do the first test on your unmodified(non-BS coated) IS with a couple of known sources, one floody one spot? Then as time permits finish the unpgrade and retest. The results should be almost identical to doing two consecutive tests with identical spheres.
    GL
    Well that is not really a deviation as I was already planning on that. I just wasn't planning on doing a test with a bunch of different colors.

  20. #20
    Flashaholic* ti-force's Avatar
    Join Date
    Jan 2009
    Location
    Georgia, U.S.
    Posts
    1,266

    Default Re: Improving the DIY integrating sphere

    Saabluster,

    Thanks for spending your time to do these tests. Do you still have the two small pieces of foam set up with your meter mounted to try one more test? Could you scuff the surface of another piece of foam with sandpaper so it takes some of the sheen off the surface of the foam, then test to see if that makes much difference? Try a fine grit paper.
    Last edited by ti-force; 04-18-2011 at 04:17 PM.

  21. #21

    Default Re: Improving the DIY integrating sphere

    Quote Originally Posted by ti-force View Post
    Saabluster,

    Thanks for spending your time to do these tests. Do you still have the two small pieces of foam set up with your meter mounted to try one more test? Could you scuff the surface of another piece of foam with sandpaper so it takes some of the sheen off the surface of the foam, then test to see if that makes much difference? Try a fine grit paper.
    Sure I can do that. I'll also try the test I already did but with a little bit more accuracy as to the angle between the two lights instead of just guessing the angle I am holding it at.

  22. #22

    Default Re: Improving the DIY integrating sphere

    what is the brand name and model number of the light meter you are using? I would add a UV light into the mix. If the meter has the proper photopic filter in it, it should not read the UV light. There may be a very tiny amount of blue light that it does read, but if it reads higher readings than an actual blue LED than you know something is wrong. As I mentioned previously, I had one meter that did that (actually read higher than the green LED I was using) and sent it back for credit.

  23. #23

    Default Re: Improving the DIY integrating sphere

    Quote Originally Posted by MrGman View Post
    what is the brand name and model number of the light meter you are using? I would add a UV light into the mix. If the meter has the proper photopic filter in it, it should not read the UV light. There may be a very tiny amount of blue light that it does read, but if it reads higher readings than an actual blue LED than you know something is wrong. As I mentioned previously, I had one meter that did that (actually read higher than the green LED I was using) and sent it back for credit.
    It is the Extech 407026. I tested it with a UV light already and it barely reads it at all.

  24. #24

    Default Re: Improving the DIY integrating sphere

    Thanks for the info. I cannot trust a "Heavy" duty "Light" meter. That's just too much of a contradiction. It would be nice to know how it does the changes for different color temperature lights. Normally you need 3 different color sensors to know what the color of the light is or a true spectral radiometer.
    Last edited by MrGman; 04-19-2011 at 02:28 PM.

  25. #25

    Default Re: Improving the DIY integrating sphere

    Quote Originally Posted by MrGman View Post
    Thanks for the info. I cannot trust a "Heavy" duty "Light" meter. That's just too much of a contradiction. It would be nice to know how it does the changes for different color temperature lights. Normally you need 3 different color sensors to know what the color of the light is or a true spectral radiometer.
    The reason they call it heavy-duty is because it comes with a removable hefty rubber cover to protect the meter. It is made for professionals not hobby work. So no contradiction there.

  26. #26

    Default Re: Improving the DIY integrating sphere

    Quote Originally Posted by ti-force View Post
    Saabluster,

    Thanks for spending your time to do these tests. Do you still have the two small pieces of foam set up with your meter mounted to try one more test? Could you scuff the surface of another piece of foam with sandpaper so it takes some of the sheen off the surface of the foam, then test to see if that makes much difference? Try a fine grit paper.
    OK so I finally got around to doing the test with the sandpaper. It did indeed have a very good effect. Here's the numbers.

    --------------------90°(perpendicular) 20°
    Bare unsanded foam__ 9 ____________ 123
    Foam coated in BS ___11 ____________ 16
    Sanded foam ________11 ____________ 29

    Pretty remarkable change and a very simple and effective way to improve the diffusing ability of the foam. It will not however change the fact that it is throwing off the spectrum some but it is hard at this point to say how much. BTW I used a 400 grit wetsanding sandpaper. I really wouldn't use a real heavy sandpaper on there as the rougher kinds may snag the surface.
    Last edited by saabluster; 05-11-2011 at 08:31 PM.

  27. #27

    Default Re: Improving the DIY integrating sphere

    One more update on how well the BS performs vs sanded foam as it relates to spectrum. I bought a 4sevens quark RGB to use as a calibration tool since it has excellent regulation and would also make it easy to test how well different surfaces reflect at different wavelengths. I used the same pieces of foam I used in the first experiment and found no appreciable difference in how well the BS and bare foam reflected red, green, and blue.

    I also sanded the foam a little heavier than before but it did not improve the diffusing ability of the bare foam. So at least in this area bare foam just cannot match the performance of the BS.

  28. #28
    Flashaholic* ti-force's Avatar
    Join Date
    Jan 2009
    Location
    Georgia, U.S.
    Posts
    1,266

    Default Re: Improving the DIY integrating sphere

    Saabluster,

    Thanks again for your time spent testing. So, as far as wavelength reflectance is concerned, do certain colors penetrate Styrofoam more than others? You stated earlier in this thread that diffusion of light from different beam angles (spot vs flood) was the biggest problem with these homemade spheres, and as your testing shows, sanding the surface to reduce glare greatly improves the ability of bare Styrofoam to diffuse light. So how much light is lost through the Styrofoam, bs vs bare Styrofoam, and how much do you think this loss would impact the accuracy for measuring lumens of cool white led's in a sphere that has been calibrated with known output lights, all of which being cool white led's?

    Thanks again.

  29. #29
    Flashaholic* Got Lumens?'s Avatar
    Join Date
    Mar 2011
    Location
    Champlain Valley
    Posts
    1,973

    Default Re: Improving the DIY integrating sphere

    Saabluster,
    Thank you for doing the testing.
    I am wondering if You have done any tests comparing Dupont's Styrofoam to "Smoothfoam"?
    Everthing I've read says that smoothfoam is, well, smoother than styrofoam with less cavitation. So my question is would smoothfoam make a better sphere than styrofoam?
    Thanks
    GL

  30. #30
    Flashaholic
    Join Date
    Nov 2005
    Location
    Spain
    Posts
    223

    Default Re: Improving the DIY integrating sphere

    I actually linked the article about using BS to enhance reflectivity and achieve a lambertian reflection 6 years ago (http://www.candlepowerforums.com/vb/showthread.php?142034-BaSO4-latex-flat-white-paint-superreflective-mix,) but there was no interest then. Probably if I had posted later DIY IS with it...

    Anyway, I post because Ive been working with BS for some time so I think sharing my experience on it would be helpful.

    The article linked did a great job quantifying the amount of BS necessary to get a reflectance close to Spectralon and more than good enough for a DIY IS. But I experienced that when using recommended amounts of BS on typical latex white paint (30% by volume, 50% by weight, give or take), the mix was very dense, so the only way to apply it is by hand, and that way is very difficult to get a layer flat and uniform. I found very interesting the way used by Saabluster to apply the BS over the applied paint, although I think that way the mix probably have way less BS to get close to Spectralon. Anyway, surely is enough to get a lambertian reflection so the IS is more reliable independent of the beam angle of the light.

    I was interested on building a more accurate IS yet, so I wanted to obtain a some millimeters thick layer with enough BS. Did it but the layer finish wasnt flat (overcame it by sanding) nor uniform. Tested with an spectroradiometer, it showed no attenuation of any wavelength along most of visible range (440 to 700nm), although it began to be noticeable below 440nm and significant at 430nm. Fortunately most white LEDs uses a royal blue LED peaking about 450nm which usually emits just about 2% of its emitted energy below 435nm so effect on Lm measurement is negligible (additionally, human sensibility below 435nm is very low, less than 20lm/optical Watt).

    I tried for some time to find a paint with a low carbonate load, in order to get a less dense mix when adding the BS. I didnt found it but recently I discovered a patented paint technology, called Lumitec (By Azko Nobel, different brand on each country) which seems to use BS as main load instead of carbonates. Just a guess, as manufacturer dont offer any detail on composition (protected info), but the fact is absolute white achieves a minimum reflection of 92% and (maybe thick layer may be close to 99%) with a lambertian reflection. Ivent tried it yet, although I plan to do it on next DIY IS, trying first it alone and adding a layer mixed with BS if reflectivity is not enough. That way should allow to spray the paint and get a uniform and flat finish. For those just trying to improve the lambertian reflection of their DIY IS, that paint could be a good way of getting it.
