PART 9 !!! P60 Style Custom Drop - in modules for SF and other Products. (part 9 can be found here)
Here I am offering P60 Style drop ins, they are available with Leds from the following manufacturers with some of the leds that will be offered are below.
SSC Seoul - P7 , P4
Cree - XML , XPG, XP-E, MC-E, XRE , UV, are here in warm , neutral or cool white
Osram - Diamond Dragon , Golden Dragon Plus, Platinum Dragon IR/
Luminus - SST -50, SST -90
These modules will fit most flashlights that accepts a standard P60/D26 Style module.
THESE DO NOT FIT OLD STYLE G2 HOSTS
IF a GREAT host is needed here are some great hosts by Five Mega to look at (HERE)
Here is one of the emitter in the base and converter board
View of the module from the top and typical beam shot
You can still see a bit of a doughnut hole in this picture but most of the time we can focus all or most of it out.
This is a picture of the reflector made for the Cree XPE XPG This gives a very smooth and concentrated hotspot.
New OPTICS Modules for XRE only
All of the modules end up being as close to standard length as possible The large die leds are much thicker and there is a small possibility that there will be a crack at the head and body. I keep all as short as possible so if there is a crack there is probably nothing that can be done.
All hosts are slightly different and one module may fit tight in a SF product and a bit loose in a FM Nite clone or an FM C but they will fit all. One may need to have the spring cut down to allow the head to close or a whole spring may be needed to keep the module from rattling. They also fit most Solarforce or any P60 style host
Most LED's are carried in Cool White, Neutral White, or Warm white when possible. They will be listed if in stock if not listed probably not in stock.
Battery configs listed are for any battery that falls into the range listed.
Potting is the filling of electronics cavity with thermal epoxy for heat management and shock protection. Copper tape is included with potting and both are included at no charge unless specified by member.
ALL MODULES ARE LEAD FREE, ALL SOLDER USED IS LEAD FREE
Seoul P7 $65 - 3.6v - 6volts ONLY /
1- 3 or 4 levels regulated /Cool White
CREE LEDS http://www.cree.com/products/xlamp.asp binning and tint informaiton (GREAT RESOURCE)
Cree XM-L $40
U2 flux bin 1A 6500k+ Cool White
T60 flux bin 3C 5000k daylight white
T50 flux Bin 4C 4300K neutral white
T40 flux bin 5B3 4000k neutral white
T40 flux bin 6A3 3500k Warm white
T30 flux bin E7 3000K Warm White
1 Level only (potting and tape included this model only) works well in the 26650 Cooly's by Five Mega.
Not made for continuous run.
1 level 2.2 amps 3.6-16 volts
best for use with Multiple cells.
Available levels with memory (2.8-6 volts only) 3Amp stock
1 level Regulated
3 level Low / Med / High Regulated
3 level Low / Hi / Strobe Regulated
4 level Low low/ low / Med / High
6 volt Drivers are 3 amps stock and can be pushed at and 3.5 amps or even 4.2 amps but high should be used for shorter periods these do work well in the 26650 Cooly's by Five Mega.
and in 2P 18650 P60 M*g 1D by Fivemega There is no extra charge for these.
If you want to use continuously on high in most hosts please use 3 amps for better heat control and you will also get much better runtime.
Either Smooth OR Op reflectors available (extra reflectors not available at this time.)
Potting with copper tape is now included
XML TOWER MODULES $80 NEW!!!!
T6 flux 1A tint *ONLY EMITTER AVAILABLE AT THIS TIME*
Any of the above 6 volt max drivers listed under XML's plus ones listed below
1 level 4-16 volt 2.2 amp driver
Fits any of the surefire turbo heads such as KT1 / KT4 / KT5
Cree XP-G -$35 *mixture of throw and flood*
2.8-6 (levels are 100% / 40% / 5% )
5 level low / med / high/ SOS / Strobe with memory / 1.4 amp
/ 1/7 amp
5 level moonlight/ low low / low / med / high 1.5 amps
3 level low / med / high 2.8-6 volts with memory / 1.4 amp / 1.7 amp
1 level 2.8-6 volts
1 Level 4-14 volts / 1.5 amp
3 levels high / med/ low / 3.6-9 volts no memory / 1.4 amp
3 level 1v-4.2 volts for low voltage for A / AA lights
Flux Bins and tints that are available for XPG
Q23000K 7A3 (90 minimum CRI) NEW
Q4 2900k 8A4 tint
R4 4000k 5B3 tint /5B2
R4 5000k 3C tint
R5 5500k - 2T tints (Cool White comparable to WH tint)
S2 6300k - 1T tints (coolwhite comparable to WF tint)
DUAL XPG (Linger Special)$45 Any of the above bins are possible / 3 level 2.8 amp 3.6-6 volts max *Floody* (levels available are same as XML)
DBS MODULES AVAILABLE ON REQUEST for most emitters
/ brass pill only no reflector/ same price as regular modules, potting is available on these also.
4500k 92CRI neutral ($35)
Driver Levels the same as the XPG's above
CREE XPC $30 (new)
Q5 WC tint available in 1 / 3 levels with memory in 1.4 or 1.7 amp
Cree XRE - XPE -$30 -
1.4 or 1.7 amp with memory
2.8 - 6 volts 3 level regulated high / med / low
2.8-6 volts 5 levels regulated - high / med / low / SOS/ strobe
3.6 -8.4V regulated @ 1.4 amps - 3 levels high / med/ low
XPE Good Throw
R2 or R3 available coolwhite / (Q3 5B)neutral /warm tints
XPE Green , Red, Amber /Blue
XRE (Good Throw )
R2 flux WF tint
8E7 warm white
Green and Blue colors
Smooth OR OP reflectors are available
Optics are for XRE emitters only / Cool white , neutral white and warm whites.
8degree/ 60 degree.
$37 for module and 1 optic $40 with 2 optics
Cree MCE $ 55 - GOOD FLOOD
1 - 3 or 5 level regulated 3.6 - 6 volts
Cool - M bin WD, WG
Cool - Nbin no tint supplied but pure white
Neutral - Kbin 5B tint
Warm bins JE5, JE6, KA3
Osram Diamond Dragon $40 - 3.6 -6 volts / 1/ 3/5 level Ultra White /WARM WHITE/True Green / Red
Platinum Dragon - $40 Hyper-Red this is a true red no orange red. __________________________________________________ ___________________________
LUMINUS SST SERIES LEDS
Luminus SST-50 - $55 -
2.8 -6volts only *good throw with adequate spill*
1 Level direct drive
Regulated with memory offered with same amperages as XML's listed above
3 level -- Low - Med - high
3 level -- low- high- strobe
4 level -- Low Low- low - med - high
Flux Bins are
6500K Cool White (W65S-GJ102-WJ-G4 )
5700k (w57S-GJ201-WJ-H4 )
4500k (w45S-GJ400-WJ-P3 )
DBS MODULES AVAILABLE ON REQUEST *pill only*
Luminus SST -90 -$70 -
2.8 -6 volts only *Floody*
1 Levels direct drive
Also available in regulated drivers with memory of the same amperage drivers used with XML's above
6500 (W65S-WN-G3 )
3000k warm 83CRI ( W30M-GK700-WK-U3 )
Green - Red- Blue Colered SST90's also available
Cree UV XL 7090 $45 (395nm)3.6 v-6volts /1 level
OSRAM IR LEDS
Osram Platinum Dragon IR $45 (850 940nm)-3.6v- 6 volts /1 level 2.8-6 volts
Quad Die 10watt IR great for night pictures
I also have
Seoul P4 - CW / Neut / warm 90 CRI
please PM for info on these modules
I try to keep the above listed led's in stock, I also try to keep the newest and most popular bins and color temps from cool whites / neutrals / and warm white high CRI models.
Now as to levels in drivers , most of the time the levels are fixed and can't be changed. As new drivers become available the offerings will change on this page so please check it first. I often will have to change depending on what drivers I have available to me at the time so please check this page and I will update as needed.
Please specify what host and batts you are using when inquiring about a module or led. Just remember if you don't see it or don't understand something just write as I don't mind helping but check this page first. These are not try and buy!
Now that said the search button for the forum has a wealth of knowledge, much more than I can ever remember and usually with in days of a new led release runtimes and lumens are often posted please check the forum's search box as it is invaluable.
When ordering please post your order in this thread plus put details in Paypal notes of what emitter and tint ordered/ include choice of reflector / # of levels / check to see if shipping address is visible . Also please list CPF Nickname in paypal notes.
Shipping is 3 working days Although next day is not unusual Shipping confirmations are sent when mailed
Make sure your address in paypal is correct becuase that IS WHERE IT WILL BE SENT.
If you want it mailed to an alternate address from the paypal address please state I want my parcel sent to an alternate address if this is not done I will think it is a duplicate address and will send to what is listed on PP.
MY Paypal info in biography or PM for it / I do not send confirmations that I received your paypal if properly addressed then I WILL receive it, you should be receiving a receipt from paypal when sent.
Shipping Conus is included 1st class,
Domestic Priority is $5 for up to 3 modules
International shipping is $5 for 1st class Int up to two modules , Priority Mail Int. is $15 up to 3 modules , express mail and more than 3 modules quoted.
Beam shots are posted below and new products will be posted below. Please send your beam shots and I will try to list when possible or create a link to them.
New offerings will be listed below as they become available.
