Thread: Solid Copper Mule D26 / P60 Mules in XML2 / XPG2 / Nichia 219

  1. #1

    Default Solid Copper Mule D26 / P60 Mules in XML2 / XPG2/XPE2 / Nichia 219

    These are solid copper mule D26 / P60 complete modules.

    We will offer these in XML2 / XPG2 / and Nichia 219
    Triples are in XPG2 / XPE2 / and nichia only.









    These are the same heat sinks that Donn just sold but are completed modules only and they are milled perfect. They are hard to work with (gloves) to keep perfect but they look great.
    The 90 cri XML2 in the picture is a perfect paring with these mules. The triple XPG2's in the picture are 3D's

    ON a side note
    Donn has tried these in about 2 dozen different hosts, and the only ones they don't fit are Moodular C-Series adapters and one of his older round-body 6P tubes. However, a tiny bit of sanding solved the fit quite nicely. They are much more snug than most drop-in bells, and should require no foil or tape to have optimal heat transfer.

    XML2 / XPG2 / Nichia singles are all on 20mm all copper direct bond Sinkpads.
    Triple XPG2's / XPE2 / Nichia's are built on Aluminum parallel boards.

    Tints available are below

    XML2
    coolwhite U2 flux 1C
    Neutral T6 flux 3C
    Neutral T5 flux 5B4
    Warm white 90cri S6 flux
    __________________________________________________ _____________________

    XPG2
    Coolwhite S2 flux 2B
    Neutral R5 flux 3D
    warm white 90 cri
    __________________________________________________ _____________________
    XPE2
    Coolwhite R3 flux 1D tint
    Neutral R2 fLux 5B4 tint
    Red / Green / blue also
    __________________________________________________ ______________________

    Nichia 219 B10 flux 4500k neutral
    __________________________________________________ ______________________


    Drivers are the same drivers I am using in the other threads.
    All have last level memory.

    Levels are 1 / 3 low med high / 4 moonlight , low , med , high

    XML2's are driven at 3 amps / XPG2's and Nichia's driven at 1.8 amps / triples are driven at 4.2 amps
    __________________________________________________ ______________________

    Prices are below and include shipping in US. We do ship International, 1st class Int is $12

    XML2 / XPG2 / Nichia mules are $85

    Triple XPG2 / Triple Nichia mules are $100

    Paypal is in my Bio

    Thanks

  2. #2

  3. #3
    Flashaholic* tobrien's Avatar
    Join Date
    Dec 2005
    Location
    Georgia Highway 441
    Posts
    4,861

    Default Re: Solid Copper Mule D26 / P60 Mules in XML2 / XPG2 / Nichia 219

    hoooooooooooly cow. these look phenomenal! nice work!
    aka Edgar Allan Bro, Brosama Bin Liftin, Walter Crunkite, Bro Namath, Teddy Brosevelt, and the Tomahawk Crunkmissile.
    my lights - review of PrecisionWorks - that's Gucci Mane in my avatar

  4. #4

    Default Re: Solid Copper Mule D26 / P60 Mules in XML2 / XPG2 / Nichia 219

    Do the triples allow for carclo optics?

  5. #5

    Default Re: Solid Copper Mule D26 / P60 Mules in XML2 / XPG2 / Nichia 219

    Quote Originally Posted by pinkpanda3310 View Post
    Do the triples allow for carclo optics?
    Hi

    These are mules, no optics no reflectors.
    The emitters are brought most of the way out to the lens and is made for a very smooth artifact free floody light.

    Dave

  6. #6

    Default Re: Solid Copper Mule D26 / P60 Mules in XML2 / XPG2 / Nichia 219

    I will take a tri 219 3 mode.
    PP sent
    Last edited by CMAG; 07-18-2013 at 06:58 AM.

  7. #7

    Default Re: Solid Copper Mule D26 / P60 Mules in XML2 / XPG2 / Nichia 219

    Quote Originally Posted by CMAG View Post
    I will take a tri 219 3 mode.
    PP sent
    Hi

    Thanks it should ship in the AM tomorrow.

    Dave

  8. #8
    yoyoman's Avatar
    Join Date
    Nov 2012
    Location
    Switzerland/Scarsdale
    Posts
    2,345

    Default Re: Solid Copper Mule D26 / P60 Mules in XML2 / XPG2 / Nichia 219

    I'll take 1 XM-L2 Warm White 90CRI 3-mode. PayPal sent.

  9. #9

    Default Re: Solid Copper Mule D26 / P60 Mules in XML2 / XPG2 / Nichia 219

    Quote Originally Posted by yoyoman View Post
    I'll take 1 XM-L2 Warm White 90CRI 3-mode. PayPal sent.
    Hi

    I have one of those made up so it will ship tomorrow AM.

    Thanks

    Dave

  10. #10
    yoyoman's Avatar
    Join Date
    Nov 2012
    Location
    Switzerland/Scarsdale
    Posts
    2,345

    Default Re: Solid Copper Mule D26 / P60 Mules in XML2 / XPG2 / Nichia 219

    Thanks, but take your time - I don't get to NY until August 2nd.

  11. #11

    Default Re: Solid Copper Mule D26 / P60 Mules in XML2 / XPG2 / Nichia 219

    Quote Originally Posted by nailbender View Post
    Hi

    Thanks it should ship in the AM tomorrow.

    Dave

  12. #12

    Default Re: Solid Copper Mule D26 / P60 Mules in XML2 / XPG2 / Nichia 219

    Quote Originally Posted by CMAG View Post
    I will take a tri 219 3 mode.
    PP sent

    HI

    Your module shipped this morning.

    thanks have a good weekend

    Dave

  13. #13
    Flashaholic* KDM's Avatar
    Join Date
    May 2012
    Location
    Tennessee
    Posts
    2,009

    Default Re: Solid Copper Mule D26 / P60 Mules in XML2 / XPG2 / Nichia 219

    So the nichia 219 single or triple are driven at 1.8 amps?

  14. #14

    Default Re: Solid Copper Mule D26 / P60 Mules in XML2 / XPG2 / Nichia 219

    Quote Originally Posted by KDM View Post
    So the nichia 219 single or triple are driven at 1.8 amps?
    The singles are driven at 1.8 amps, I did not list the triples they are 4 amps.

  15. #15
    Flashaholic* KDM's Avatar
    Join Date
    May 2012
    Location
    Tennessee
    Posts
    2,009

    Default Re: Solid Copper Mule D26 / P60 Mules in XML2 / XPG2 / Nichia 219

    OK thanks. They look great I'll be placing my order soon.

  16. #16

    Default Re: Solid Copper Mule D26 / P60 Mules in XML2 / XPG2 / Nichia 219

    Quote Originally Posted by yoyoman View Post
    I'll take 1 XM-L2 Warm White 90CRI 3-mode. PayPal sent.
    HI

    Your module shipped

    Dave

  17. #17
    Flashaholic* timbo114's Avatar
    Join Date
    Jun 2009
    Location
    by a lake in PA
    Posts
    578

    Default Re: Solid Copper Mule D26 / P60 Mules in XML2 / XPG2 / Nichia 219

    Dave,
    Which is the brighter of the neutral emitters listed for the mule?
    I'm not looking for cri for this drop in ... just smooth creamy nw goodness.

  18. #18

    Default Re: Solid Copper Mule D26 / P60 Mules in XML2 / XPG2 / Nichia 219

    Quote Originally Posted by timbo114 View Post
    Dave,
    Which is the brighter of the neutral emitters listed for the mule?
    I'm not looking for cri for this drop in ... just smooth creamy nw goodness.
    Hi

    the T6 flux 3C tint will be the brightest. It is 5000k

    next would be a t5 flux 4C tint

    Dave

  19. #19

    Default Re: Solid Copper Mule D26 / P60 Mules in XML2 / XPG2 / Nichia 219

    tri 219 came today, nice chunk of copper. tight fit

  20. #20

    Default Re: Solid Copper Mule D26 / P60 Mules in XML2 / XPG2 / Nichia 219

    Quote Originally Posted by CMAG View Post
    tri 219 came today, nice chunk of copper. tight fit
    Hi

    That made it pretty fast, it is a nice chunk of copper and quite well milled.

    have a good week

    Dave

  21. #21

    Default Re: Solid Copper Mule D26 / P60 Mules in XML2 / XPG2 / Nichia 219

    Quote Originally Posted by nailbender View Post
    Hi

    That made it pretty fast, it is a nice chunk of copper and quite well milled.

    have a good week


    Dave
    Sure did, thanks Dave.
    forgot to say nice room filling light on high,

  22. #22
    Enlightened
    Join Date
    Jul 2010
    Location
    London UK
    Posts
    95

    Default Re: Solid Copper Mule D26 / P60 Mules in XML2 / XPG2 / Nichia 219

    Hi.

    Can I take,
    1xTri Nichia 219.
    Moonlight , low , med , high
    Int Shipping.
    Total $112

    Thanks

    Kit

  23. #23

    Default Re: Solid Copper Mule D26 / P60 Mules in XML2 / XPG2 / Nichia 219

    Quote Originally Posted by kitman22 View Post
    Hi.

    Can I take,
    1xTri Nichia 219.
    Moonlight , low , med , high
    Int Shipping.
    Total $112

    Thanks

    Kit
    Hi

    No problem I will get one ready.

    Dave

  24. #24

    Default Re: Solid Copper Mule D26 / P60 Mules in XML2 / XPG2 / Nichia 219

    Quote Originally Posted by kitman22 View Post
    Hi.

    Can I take,
    1xTri Nichia 219.
    Moonlight , low , med , high
    Int Shipping.
    Total $112

    Thanks

    Kit
    HI

    Module has shipped

    Thanks

    Dave

  25. #25

    Default Re: Solid Copper Mule D26 / P60 Mules in XML2 / XPG2 / Nichia 219

    Hi.


    Can I take,
    1xTriple Nichia 219.
    Moonlight , low , med , high
    Int Shipping.
    Total $112


    Thanks
    Sam
    (Copied words from Kit, hope you don't mind as difficult input on iPhone)

  26. #26

    Default Re: Solid Copper Mule D26 / P60 Mules in XML2 / XPG2 / Nichia 219

    Quote Originally Posted by SamFoto View Post
    Hi.


    Can I take,
    1xTriple Nichia 219.
    Moonlight , low , med , high
    Int Shipping.
    Total $112


    Thanks
    Sam
    (Copied words from Kit, hope you don't mind as difficult input on iPhone)
    HI Sam

    No problem I will get one started

    Dave

  27. #27

    Default Re: Solid Copper Mule D26 / P60 Mules in XML2 / XPG2 / Nichia 219

    Quote Originally Posted by nailbender View Post
    HI Sam

    No problem I will get one started

    Dave
    Thanks, Dave.
    can you give me your PP account? I am new to here so I have't privilege to check profile.

  28. #28

    Default Re: Solid Copper Mule D26 / P60 Mules in XML2 / XPG2 / Nichia 219

    Quote Originally Posted by SamFoto View Post
    Thanks, Dave.
    can you give me your PP account? I am new to here so I have't privilege to check profile.
    Hi

    PM sent with PP addy, since I can send you a PM you do have privileges now. Usually you are vetted after 3 posts.

    thanks

    Dave

  29. #29
    Enlightened
    Join Date
    Jul 2010
    Location
    London UK
    Posts
    95

    Default Re: Solid Copper Mule D26 / P60 Mules in XML2 / XPG2 / Nichia 219

    Quote Originally Posted by nailbender View Post
    HI

    Module has shipped

    Thanks

    Dave
    Noted.
    Thanks mate.

  30. #30

    Default Re: Solid Copper Mule D26 / P60 Mules in XML2 / XPG2 / Nichia 219

    Hi Dave,
    for 1 Copper Mule Triple XPG2 R5 3D.

    Thanks!

    Joe
