(AVAILABLE)


NOTE: Please allow 7 days to ship
Continue from:
here

Please note: I will not send email or PM to individuals regarding payment confirmation and shipping status.
All these information will be next to your CPF handle in this post.
All 50 States shipping will come with tracking number but for international orders I will provide label number. Sorry, no tracking available for international orders.

M*g D Incandescent



NO RESERVATION


Here is another innovation from FiveMega
A ceramic heat sinked socket to fit all G6.35, GY6.35, G5.3, G4 and GU4 bi pin bulbs.
Just remove switch from your M*g D, cut off tower and solder two wires to switch positive and negative contacts.
It will be easier to remove switch stopper C clamp and install switch from head side, install C clamp back then insert bi pin brass assembly using pair of niddle nose pliers. By pushing pliers, brass will fit inside M*g D barrel and soon as you remove pliers, it will stop there and wont move.
Picture shows how to insert brass socket into M*g D barrel in right side and installed Osram 458 on left side.
It is easily possible to adjust bulb fillament height which should be about 2mm above barrel lip.
Since socket is mounted on brass and brass is directly in contact with flashlight barrel, heat will transfer faster to body and won't damage switch.
What you get is installed ceramic socket inside brass mount. No switch, no flashlight body, no head no batteries, no charger and no plier included.
This socket is designed to work with new M*g D with D in front of serial number. Wont fit M*g C
Please see: battery holders here and here.
G4 drop in sockets here.
G5.3 drop in sockets are here.
Price:
Standard $24 each (A V A I L A B L E)
Premium $26 each (Low resistance Teflon wires) (A V A I L A B L E)
Buy two sockets and get $10 off
Shipping to States $6 each
Shipping internationally $16 for each socket.
Please pay first, pick next available number, post it here and same information in paypal note or message.
Without above information, I will never figure out who is paying and for what item(s).
Paypal:
[email protected]
All international packages must be with printed name and address in English and include a phone number.
------------------------
Standard G6.35 & G4 Socket

#01 G6.35 socket $24 Nova paid shipped
#02 G6.35 socket $24 Xuen7 paid shipped LC548066897US
#03 G6.35 socket $24 atolchev paid shipped LC548066910US
#04 G6.35 socket $24 jwyj paid shipped 23082180000028858784
#05 G6.35 socket $24 jwyj paid shipped 23082180000028858784
#06 G6.35 socket $24 DrSwiger paid 03103490000027886148
#07 G6.35 socket $24 LightJunk paid shipped 03103490000027889958
#08 G6.35 socket $24 LightJunk paid shipped 03103490000027889958
#09 G6.35 socket $24 LightJunk paid shipped 03103490000027889958
#10 G6.35 socket $24 LightJunk paid shipped 03103490000027889958
#11 G6.35 socket $24 jwyj paid shipped LC523845605US
#12 G6.35 socket $24 FBsLights paid shipped 03110240000020027642
#14 G6.35 socket $24 FBsLights paid shipped 03110240000020027642
#15 G6.35 socket $24 1pt21 paid shipped 03110240000020037788
#16 G6.35 socket $24 Eirik paid shipped LC548067380US
#17 G6.35 socket $24 mckeand13 paid shipped 03103490000199366622
#18 G6.35 socket $24 EMC2 paid shipped 03103490000199366615
#19 G6.35 socket $24 LMVDIRECT paid shipped LC452768324US
#20 G6.35 socket $24 Nightman paid shipped LC452768369US
#21 G6.35 socket $24 Nightman paid shipped LC452768369US
#22 G6.35 socket $24 ErikP paid shipped 23051590000171668697
#23 G6.35 socket $24 kcdunn1 paid shipped 03112550000196289842
#24 G6.35 socket $24 Brian S paid shipped 03112550000196289873
#25 G6.35 socket $24 ss2nv paid shipped 03113260000161335960
#26 G6.35 socket $24 ss2nv paid shipped 03113260000161335960
#27 G6.35 socket $24 LightJunk paid shipped 03113260000161340698
#28 G6.35 socket $24 LightJunk paid shipped 03113260000161340698
#29 G6.35 socket $24 gVp paid shipped LC452889591US
#30 G6.35 socket $24 alby26 paid shipped 03112550000058021375
#31 G6.35 socket $24 jmpaul320 paid shipped 03112550000058021016
#32 G6.35 socket $24 jmpaul320 paid shipped 03112550000058021016
#33 G6.35 socket $24 lctorana paid shipped LC360750438US
#34 G6.35 socket $24 ming560 paid shipped LC740353711US
#35 G6.35 socket $24 ming560 paid shipped LC740353711US
#36 G6.35 socket $24 ma_sha1 paid shipped 03113260000160937004
#37 G6.35 socket $24 Louis-Marie Viel paid shipped LC360722746US
#38 G6.35 socket $24 mjgsxr paid shipped LC931050960US
#39 G6.35 socket $24 lngrnge paid shipped 9505510529973108522439
#40 G6.35 socket $24 LMVDIRECT paid shipped 740354164US
#41 G6.35 socket $24 miss breezy paid shipped 9114901159818849074607
#42 G6.35 socket $24 charlestt paid shipped LC007682604US
#43 G6.35 socket $24 Nancy paid shipped 9114901159818848933455
#44 G6.35 socket $24 ef9sleeper paid shipped LC658428987US
#45 G6.35 socket $24 StorminMatt paid shipped 9114901159815942834596
#46 G6.35 socket $24 SVARO paid shipped LC186124206US
#47 G6.35 socket $24 tomthebaker paid shipped 23082940000035337924
#48 G6.35 socket $24 Bimmerboy paid shipped 9114901159815876935826
#49 G6.35 socket $24 Hallis paid shipped 9114901159815876935833
#50 G6.35 socket $24 Hallis paid shipped 9114901159815876935833
#51 G6.35 socket $24 Conte paid shipped LC435915504US
#52 G6.35 socket $24 double0thirteen paid shipped LC550404580US
#53 G6.35 socket $24 double0thirteen paid shipped LC550404580US
#54 G6.35 socket $24 Maker paid shipped 9114999944238373431092
#55 G6.35 socket $24 Maker paid shipped 9114999944238373431092
#56 G6.35 socket $24 Maker paid shipped 9114999944238373526392
#57 G6.35 socket $24 Maker paid shipped 9114999944238373526392
#58 G6.35 socket $24 Domdom paid shipped LC550399607US
#59 G6.35 socket $24 Domdom paid shipped LC550399607US
#60 G6.35 socket $24 jkpq45 paid shipped 9500111140525028592392
#61 G6.35 socket $24 jkpq45 paid shipped 9500111140525028592392
#62 G6.35 socket $24 breadfan paid shipped 9114999944238373413746
#63 G6.35 socket $24 BlackEgoBrain paid shipped LC529139177US
#64 G6.35 socket $24 MadeInUSA paid shipped 9505511144965083556165
#65 G6.35 socket $24 bigchelis paid shipped 9500111144965103527349
#66 G6.35 socket $24 cloudbounce paid shipped LC550834540US
#67 G6.35 socket $24 GBOGH paid shipped 9505513808436019092453
#68 G6.35 socket $24 mjgsxr paid shipped LC722226889US
#69 G6.35 socket $24 ozrj paid shipped LC186109291US
#70 G6.35 socket $24 bigchelis paid shipped 9500113808416123152288
#71 G6.35 socket $24 mjgsxr paid shipped LC722226787US
#72 G6.35 socket $24 mjgsxr paid shipped LC722226787US
#73 G6.35 socket $24 mjgsxr paid shipped LC722226787US
#74 G6.35 socket $24 mjgsxr paid shipped LC722226787US
#75 G6.35 socket $24 id30209 paid shipped LA046595306US
#76 G6.35 socket $24 TorchBear paidshipped LH127610391US
#77 G6.35 socket $24 mesa232323 paid shipped 9500113808431033367799
#78 G6.35 socket $24 strideredc paid shipped LH163990468US
#79 G6.35 socket $24 bridgman paid shipped
#80 G6.35 socket $24 Chicken Drumstick paid shipped LH183829113US

#81 G6.35 socket $24 (A V A I L A B L E)
#82 G6.35 socket $24 (A V A I L A B L E)
#83 G6.35 socket $24 (A V A I L A B L E)
#84 G6.35 socket $24 (A V A I L A B L E)
#85 G6.35 socket $24 (A V A I L A B L E)
#86 G6.35 socket $24 (A V A I L A B L E)
----------------------

Premium=Low Resistance Teflon Wires.
#01 G6.35 premium socket $26 mesa232323 paid shipped 9505513808411152378695
#02 G6.35 premium socket $26 mesa232323 paid shipped 9505513808411152378695

#03 G6.35 premium socket $26 (A V A I L A B L E)
#04 G6.35 premium socket $26 (A V A I L A B L E)
#05 G6.35 premium socket $26 (A V A I L A B L E)
#06 G6.35 premium socket $26 (A V A I L A B L E)
#07 G6.35 premium socket $26 (A V A I L A B L E)
#08 G6.35 premium socket $26 (A V A I L A B L E)


----------------------
Please find link of my other products here and click on each link you are interested.


(A V A I L A B L E)

Last edited:

fivemega

Flashlight Enthusiast
CPF Supporter
Joined
Jan 28, 2003
Messages
5,390
Location
California
Questions?

Do these require a custom reflector to avoid melting?
Any bulb over 10W in M*g "C" and M*g "D" will produce too much heat and needs Aluminum Reflector and glass lens.
Bulbs less than 10 W don't produce high temperature and can be used with M*g "C" and M*g "D" original plastic reflector and lens.
