Sold/Expired 1000 Lumens E2 Fire by FiveMega

fivemega

Flashlight Enthusiast
Joined
Jan 28, 2003
Messages
5,550
Location
California
(AVAILABLE)


Please allow 7 days to ship


Please note: I will not send email or PM to individuals regarding payment confirmation and shipping status.
All these information will be next to your CPF handle in this post.
All 50 States shipping will come with tracking number but for international orders I will provide label number. Sorry, no tracking available for international orders.




Upper left: Gray 2x18350 __ Upper Middle: Gray 2x18350 with CL1499 __ Lower right: Black 2x18350 with installed head (NOT INCLUDED)



Please first read completely,

then pay

lastly post detail of your order here

Here are another interesting addition to your favorite E series.
These bodies are designed to use with 18XXX Li-Ion batteries to make your incan E $urefire the most powerfull ever made.
Body is slightly fatter than original body which takes 18350 and 18500 cells with more aggressive round knurling (No flat sides). Tail side is "C" compatible and can be loaded from tail side. A bi-pin socket is installed and you won't need to buy any socket.
Basicaly, you convert your E series $urefire to either 2x18350 (will work with 2x16340 too) or 2x18500 from smallest to long run pocket friendly flashlight while you get about 1000 bulb lumens from a FM1794 bulb or 400 bulb lumens from CL1499. Completly hard anodized to match as close as possible to natural HA or black. Inner diameter of all bodies are good to use IMR 18350 or protected 18500 cells.
Minimum inside diameter is 18.75mm
Come with installed McClicky tail cap, switch seal and all necessary o'rings.
Simply install proper bulb on loaded body, instal original incand head and ready to go. Allways reversible and you keep original body intact and scratch free.
Excellent choice when used with 2 IMR 16340 cells, 2 IMR 18350 or 2 protected 18500 only.
What you get is body only with installed bi-pin socket. Tail cap is available and extra. NO head, NO bulb and NO battery comes with it.
Do not use 2 IMR 18500 because they may put too much stress on following bulbs.

Run time and possiblities:
1499 with 2 IMR 18350 about 20 minutes.
1794 with 2 IMR 18350 about 14 minutes.
1499 with 2 protected 18500 about 42 minutes.
1794 with 2 protected 18500 about 28 minutes.
----------------------------
There is no other battery set up or bulb possibility that I am aware of.

No reservation please. You must pay FIRST then claim your spot by posting here. I will sign your name right after receiving payment unless you paying by MO.
Please don't pay if you may change your mind. There will not be any refund.
It is ABSOLUTELY NECESSARY to pick next available and valid number, post detail of your order here and paypal note along with your CPF handle.
It is ABSOLUTELY NECESSARY to pick next available and valid number, post detail of your order here and paypal note along with your CPF handle.
It is ABSOLUTELY NECESSARY to pick next available and valid number, post detail of your order here and paypal note along with your CPF handle.
I will never figure out what for is your payment and from whom without above information therefore I will reject payment.
Price: Cash or CC
2x18350 With Tail Cap $54 (AVAILABLE)
2x18500 With Tail Cap $58 (AVAILABLE)
2x18350 Without Tail Cap $30 (AVAILABLE)
2x18500 Without Tail Cap $34 (AVAILABLE)
CL1499 $9 each (NOT AVAILABLE) (WITH PURCHASE OF BODY)
FM1794 $10 each (NOT AVAILABLE) (1000 Lumens)
Extra replacement GID switch seal $1 (AVAILABLE)
Extra replacement black switch seal $1 (AVAILABLE)
Extra replacement orange switch seal $1 (AVAILABLE)
Shipping to States $5 any quantity
Internationaly $9 each
Free shipping if paid by US postal money order.
Please pay first for next available and valid number then post it here.
Detail of items you pay is necessary and critical in paypal note or don't expect to receive.
Example: :paypal: already sent for #52 black 2x18350
CPF handle: MikeB
Michael
Paypal: [email protected]


Please PM for other type of payment.

-------------------------

#01 Gray E series 2x18350 body $54 ideefixe paid shipped 03092880000110382683
#02 Gray E series 2x18350 body $54 Hack On Wheels paid shipped LC547810897US
#03 Gray E series 2x18350 body $54 crf paid shipped 03101230000057513560
#04 Gray E series 2x18350 body $54 bigchelis paid shipped 03092880000110388128
#05 Gray E series 2x18350 body $54 m@tty paid shipped LC547811155US
#06 Gray E series 2x18350 body $54 blackbalsam paid shipped 03103490000027790995
#07 Gray E series 2x18350 body $54 blackbalsam paid shipped 03103490000027790995
#08 Gray E series 2x18350 body $54 blackbalsam paid shipped 03103490000027790995
#09 Gray E series 2x18350 body $54 Glow_Worm paid shipped 03103490000026484116
#10 Gray E series 2x18350 body $54 scout24 paid shipped 03103490000026448606
#11 Gray E series 2x18350 body $54 wrf paid shipped 23082180000028857473
#12 Gray E series 2x18350 body $54 wrf paid shipped 23082180000028857473
#14 Gray E series 2x18350 body $54 echuang paid shipped 95001105183530435641


------------------------
#01 Gray E series 2x18350 body without tail cap $30 akula88 paid shipped LC105690906US
#02 Gray E series 2x18350 body without tail cap $30 hombreluhrs paid shipped 9114901230801136177956


------------------------
#01 Black E series 2x18350 body $54 naked2 MO received shipped 03092880000110382713
#02 Black E series 2x18350 body $54 lctorana paid shipped LC547817541US
#03 Black E series 2x18350 body $54 Iliger paid shipped LC547811212US
#04 Black E series 2x18350 body $54 iqwozpoom paid shipped 03093220000077958465
#05 Black E series 2x18350 body $54 run4jc paid shipped 03103490000026448668
#06 Black E series 2x18350 body $54 ledcarry paid shipped 03103490000027883512
#07 Black E series 2x18350 body $54 ledcarry paid shipped 03103490000027883512
#08 Black E series 2x18350 body $54 abanytime paid shipped 23082940000002467760
#09 Black E series 2x18350 body $54 morepho87 paid shipped 0114901159818849095091
#10 Black E series 2x18350 body $54 Redhat703 paid shipped 9114901123086511188869
#11 Black E series 2x18350 body $54 yellow paid shipped LC658424035US

#12 Black E series 2x18350 body $54 Mesa232323 paid
#14 Black E series 2x18350 body $54 (With Penta Cap)(AVAILABLE)
-------------------------
#01 Black E series 2x18350 body without tail cap $30 naked2 MO received shipped 03103490000027985599
#02 Black E series 2x18350 body without tail cap $30 Darien paid shipped 03112550000057989867
#03 Black E series 2x18350 body without tail cap $30 Darien paid shipped 03112550000057989867
#04 Black E series 2x18350 body without tail cap $30 akula88 paid shipped LC105690906US
#05 Black E series 2x18350 body without tail cap $30 Redhat703 paid shipped 9114901123086511188869
#06 Black E series 2x18350 body without tail cap $30 diverx paid shipped 9114901159815876935819
#07 Black E series 2x18350 body without tail cap $30 ma tumba paid shipped


==============
==============
#01 Gray E series 2x18500 body $58 crf paid shipped 0310123000005751356
#02 Gray E series 2x18500 body $58 arewethereyetdad paid shipped 03103490000026448583
#03 Gray E series 2x18500 body $58 arewethereyetdad paid shipped 03103490000026448583
#04 Gray E series 2x18500 body $58 DUQ paid shipped LC548067115US
#05 Gray E series 2x18500 body $58 wrf paid shipped 23082180000028857473
#06 Gray E series 2x18500 body $58 wrf paid shipped 23082180000028857473
#07 Gray E series 2x18500 body $58 wrf paid shipped 23082180000028857473
#08 Gray E series 2x18500 body $58 wrf paid shipped 23082180000028857473
#09 Gray E series 2x18500 body $58 wrf paid shipped 23082180000028857473
#10 Gray E series 2x18500 body $58 wrf paid shipped 23082180000028857473
#11 Gray E series 2x18500 body $58 Redhat703 paid shipped 9114901159815961076915
#12 Gray E series 2x18500 body $58 vestureofblood paid shipped 9114999944238373413784
#14 Gray E series 2x18500 body $58 Mesa232323 paid

-------------------------


--------------------
#01 Black E series 2x18500 body $58 m@tty paid shipped LC547811155US
#02 Black E series 2x18500 body $58 wrf paid shipped 23082180000028857473
#03 Black E series 2x18500 body $58 wrf paid shipped 23082180000028857473
#04 Black E series 2x18500 body $58 wrf paid shipped 23082180000028857473
#05 Black E series 2x18500 body $58 wrf paid shipped 23082180000028857473
#06 Black E series 2x18500 body $58 wrf paid shipped 23082180000028857473
#07 Black E series 2x18500 body $58 wrf paid shipped 23082180000028857473
#08 Black E series 2x18500 body $58 wrf paid shipped 23082180000028857473
#09 Black E series 2x18500 body $58 wrf paid shipped 23082180000028857473
#10 Black E series 2x18500 body $58 wrf paid shipped 23082180000028857473
#11 Black E series 2x18500 body $58 abanytime paid shipped 23082940000002467760
#12 Black E series 2x18500 body $58 bigretic paid shipped 9500110670283112473635
#14 Black E series 2x18500 body $58 chicojneto paid shipped LC658428942US


-------------------------
#01 Black E series 2x18500 body without tail cap $34 JNORDON paid shipped 03103490000027985520
#02 Black E series 2x18500 body without tail cap $34 m@tty paid shipped LC452889530US
#03 Black E series 2x18500 body without tail cap $34 Darien paid shipped 03112550000057989867
#04 Black E series 2x18500 body without tail cap $34 Darien paid shipped 03112550000057989867
#05 Black E series 2x18500 body without tail cap $34 morepho87 paid shipped 0114901159818849095091
#06 Black E series 2x18500 body without tail cap $34 hombreluhrs paid shipped 9114901230801136177956


------------------------
Please find link of my other products here and click on each link you are interested on.
------------------------

(A V A I L A B L E)

Last edited:

fivemega

Flashlight Enthusiast
Joined
Jan 28, 2003
Messages
5,550
Location
California
What is the inner diameter of 2x16340 body? Does it accept 18mm. batteries?
Inside diameter of 2x16340 body is 18.75mm and AW's protected 18650 will fit freely but voltage will be too low to power up mentioned bulbs. So 2x18350 will fit perfectly.

Can the 1794 bulb start a fire from the E2e head?
Sure it can.

Hi fivemega, does your e series turbo head fit on this?
Unfortunately will not.
These bodies are designed to focus 1794 in stock head.


Hack On Wheels

Enlightened
Joined
Nov 4, 2007
Messages
774
Location
Canada
Unfortunately will not.
These bodies are designed to focus 1794 in stock head.

Would it be possible to adjust the focus by leaving the bulb with longer leads (and/or shimming it) or adjusting the integrated bi-pin adapter? Having the option of running the E2 turbo head would be invaluable.


fivemega

Flashlight Enthusiast
Joined
Jan 28, 2003
Messages
5,550
Location
California
Would it be possible to adjust the focus by leaving the bulb with longer leads (and/or shimming it) or adjusting the integrated bi-pin adapter? Having the option of running the E2 turbo head would be invaluable.
Since CL1499 bulb comes with uncut legs, it is possible to cut the legs with proper length to lift the bulb envelope few mm higher in socket. In this case, focusing will be perfect using Turbo head.


Hack On Wheels

Enlightened
Joined
Nov 4, 2007
Messages
774
Location
Canada
Since CL1499 bulb comes with uncut legs, it is possible to cut the legs with proper length to lift the bulb envelope few mm higher in socket. In this case, focusing will be perfect using Turbo head.

Sounds promising, thanks for the reply! Do you know if this would be the same for the 1794 if I can get a hold of some?


naked2

Enlightened
Joined
Jul 13, 2007
Messages
903
Location
Upland, CA
Varooj, glad to be first up on one of these! :twothumbs

#01 Black E series 2x16340 body =$54
2x CL1499 $9 each =$18
total =$72

Will send MO tomorrow
Thanks, Tony


Iliger

Newly Enlightened
Joined
Sep 28, 2008
Messages
144
Location
Moscow, Russia
Does the tail cap accept any AW softstart switch? Is it compatible with Magfire?
I have a crazy plan to use one of these bodies with M3 head. Two adapters (E to C, C to M), a little modification of M3 head reflector... Can't imagine how it will look.. :thinking:


fivemega

Flashlight Enthusiast
Joined
Jan 28, 2003
Messages
5,550
Location
California
Does the tail cap accept any AW softstart switch? Is it compatible with Magfire?
I have a crazy plan to use one of these bodies with M3 head. Two adapters (E to C, C to M), a little modification of M3 head reflector... Can't imagine how it will look.. :thinking:

Tail cap is same as McClicky $urefire "C" but different outside look and one can be used instead of other.

Magfire also can take either pentagon McClicky $urefire "C" tail cap or simple tail caps in above picture.

If I understood you correctly, you want a $urefire "M" head, "C" tail and 2x16340 body. Right?

If so, then they are readily available here.

Last edited:

lctorana

Flashlight Enthusiast
Joined
Jun 28, 2007
Messages
2,123
Location
Melbourne, Australia
:paypal: for:
#02 Black E series 2x16340 body $54
1 x CL1499 $9
Extra replacement black switch seal $1
1 x 6AA to 2D adaptor $37
International Shipping $9

Total $110


naked2

Enlightened
Joined
Jul 13, 2007
Messages
903
Location
Upland, CA
If you get to the post office early Tuesday, it might make it by Wednesday; otherwise, I'll get to play with it when I get home (following Tuesday).


ideefixe

Newly Enlightened
Joined
Feb 6, 2007
Messages
96
Location
Oregon, USA
Nice!

:paypal:

#01 Gray E series 2x16340 body $54
Extra replacement black switch seal $1
Shipping $5

$60


edit: oops...forgot to include my address...I've PM'd you....thanks!

Last edited:

ideefixe

Newly Enlightened
Joined
Feb 6, 2007
Messages
96
Location
Oregon, USA
I can't believe there's not more interest in these things! :whistle:
I love mine! :devil:

Yeah, same here...love mine too! Knurling is just right on this one and the McClicky, oh man....awesome!

Although, it's not intended to be used with the LED heads, I took out my dremel and did some grinding to have it mate with an KX2. Remember folks, not recommending that you do this, just saying imagine the possible configurations.



maxspeeds

Flashlight Enthusiast
Joined
Jan 24, 2007
Messages
2,178
Location
Oahu, Hawaii
Yeah, same here...love mine too! Knurling is just right on this one and the McClicky, oh man....awesome!

Although, it's not intended to be used with the LED heads, I took out my dremel and did some grinding to have it mate with an KX2. Remember folks, not recommending that you do this, just saying imagine the possible configurations.

Out of curiosity, what's the advantage over using a E2e body, or the stock LX2? If it fit 18650's, I could see doing that.
