Sold/Expired $urefire E2 Mini Turbo Head

fivemega

Flashlight Enthusiast
Joined
Jan 28, 2003
Messages
5,550
Location
California
(C L O S E D)





PLEASE READ CAREFULLY BEFORE YOU ATTEMPT TO BUY.


NO RESERVATION

These MINI TURBO HEADs are another innovation from FiveMega for your favorite $urefire E2 series.
With adding these TH kits, not only you will have most brightest E2 flashlight in the world but you will get much more throw and beam will be adjustable too.
With these mini TH you MUST use your own E series Bi-Pin Socket and CL1499 which produces over 385 bulb lumens (LO) or CL1794 for 1000 bulb lumens HO). (No other lamps can be used)
Simply install 2 IMR 16340 in the body, install mentioned lamp assembly and use TH instead of original head.
ATTENTION: Do not charge batteries over 4.10 volt
What you get in this thread is finned turbo head, bezel, reflector, glass lens o'rings and ONE 1499 bulb which called a Kit for $49
Body, tail cap, bulb socket, batteries and chargers are not included.
You can also use these THs with your 2x18500 bodies too.
These Mini Turbo Heads are available in HA Black or Mil spec natural gray only.
No reservation please. You must pay FIRST then claim your spot by posting here. I will sign your name right after receiving payment unless you paying by MO.
Please don't pay if you may change your mind. There will not be any refund.
It is ABSOLUTELY NECESSARY to pick next available color and and valid number, post detail of your order here and same information in paypal note along with your CPF handle.
It is ABSOLUTELY NECESSARY to pick next available color and valid number, post detail of your order here and same information in paypal note along with your CPF handle.
It is ABSOLUTELY NECESSARY[/SIZE] to pick next available color and valid number, post detail of your order here and paypal note along with your CPF handle.
I will never figure out what for is your payment and from whom without above information therefore I will reject payment.
STOP. Please do not buy if you plan not to follow above easy instruction.
Example: Ms. Brook :paypal: for:
#55 Black $49
1 Extra 1499 $9
Shipping to States $4
---------------------
Price: $49 Kit (NOT AVAILABLE)
Kit without bulb $40 (NOT AVAILABLE)
Extra 1499 $9 (NOT AVAILABLE)
Shipping to States: $4
Internationally: $5
Paypal:
DO NOT PAY
Please PM for other type of payment only.
---------------------

[SIZE=-2]#01 Black kit dcaprilia paid shipped 0309288000011043XXXX
#02 Black kit senna94 paid shipped 0309288000011110XXXX
#03 Black kit Jay T paid shipped 0309288000011110XXXX
#04 Black kit nailbender paid shipped 0309288000011110XXXX
#05 Black kit Ferry paid shipped LC138288111US
#06 Black kit mikevelarde paid shipped LC138288142US
#07 Black kit donn_ paid shipped 2308218000002887XXXX
#08 Black kit donn_ paid shipped 2308218000002887XXXX + 03080730000166855615
#09 Black kit rdh226 paid shipped 03080730000166856223
#10 Black kit rdh226 paid shipped 03080730000166856223
#11 Black kit rjr104 paid shipped
#12 Black kit my_gentle_cry paid shipped CP238160170US
#14 Black kit Roc shipped LC547924885US
#15 Black kit Roc shipped LC547924885US
#16 Black kit Roc shipped LC547924885US
#17 Black kit lctorana paid shipped LC547817657US
#18 Black kit Iliger paid shipped LC547811212US
#19 Black kit m@tty paid shipped LC547811155US
#20 Black kit fabienne paid shipped LC548067495US
#21 Black kit fabienne paid shipped LC548067495US
#22 Black kit run4jc paid shipped 03103490000027897120
#23 Black kit dbleznak paid shipped 03110240000019894736
#24 Black kit Darien paid shipped 03112550000057989362[/SIZE]
---------------------
#01 Black (BLEMISHED $5 OFF) Mike Docherty paid shipped 03103490000199596883
---------------------
[SIZE=-2]#01 Gray kit dcaprilia paid shipped 0309288000011043XXXX
#02 Gray kit iflyjts paid shipped 0309288000011110XXXX
#03 Gray kit nailbender paid shipped 0309288000011110XXXX
#04 Gray kit lctorana paid shipped LC138288125US
#05 Gray kit RichS paid shipped 0309288000011043XXXX
#06 Gray kit cernobila paid shipped LC547565012US
#07 Gray kit OscarTheDog paid shipped 0309033000010309XXXX
#08 Gray kit iflyjts paid shipped 03080730000166847061
#09 Gray kit rjr104 paid shipped
#10 Gray kit scalez paid shipped 23082180000028860916
#11 Gray kit Nite paid shipped 03092880000117167221
#12 Gray kit Nite paid shipped 03092880000117167221
#14 Gray kit dannyk paid shipped LC547780308US
#15 Gray kit lctorana paid shipped LC547817657US
#16 Gray kit Hack On Wheels paid shipped LC547810897US
#17 Gray kit crf paid shipped 03101230000057970042
#18 Gray kit crf paid shipped 03101230000057970042
#19 Gray kit m@tty paid shipped LC547811155US
#20 Gray kit JNORDON paid shipped 03103490000027985520
#21 Gray kit yellow paid shipped LC548063697US
#22 Gray kit Darien paid shipped 03112550000196289880
#23 Gray kit JasonH paid shipped 03112550000057987023
#24 Gray kit labrat paid shipped LC452889628US[/SIZE]
---------------------
Please find link of my other products here and click on each link you are interested on.

Last edited:

fivemega

Flashlight Enthusiast
Joined
Jan 28, 2003
Messages
5,550
Location
California
would stock surefire lamps physically not fit?
May fit but won't focus.

why do you say this is limited to using a CL1499 bulb, would a Strion or TL-3 bulb not work well?
Strion and TL-3 bulbs are shorter than 1499 and again won't focus.

I'm assuming the Grey would be similar in finish to your E-series bodies?
That's correct and pretty close to $urefire gray colors.

QUESTION: What is the run-time on this setup using the CL1499 and the IMR 16340 batteries?
15 minutes with pair of IMR16340
And 45 minutes using 2 protected 18500


Will the stock Surefire clicky tailcap switches handle the current draw of these lamps?
This set up takes under 2 Amps and I don't think $urefire clicky fail.
It works for me just fine.


What's the size of the reflector, and is it removable?
Reflector diameter is about 25mm with LOP texture and of course removeable.

FM 1794 won't focus in this either?
Will fit and focus perfectly if you have or can obtain one. :thumbsup: :thumbsup: :thumbsup:

I received mine today and noticed that there is some assembly required regarding the Carly lamp. The stems are very long and when installed hit the inside glass of the turbo head. Any suggestions as to exactly how long to cut these or is it just trial and error?

All CL1499 bulbs come with uncut legs or pins. You need to cut and shorten the pins to length of about 4.5mm from buttom of bulb glass.
Make sure to trim end of bulb pins.


I was wondering if your E-series Mini Turbo Head can be used with a P60 type drop in?

No, it can't.

Is there an available 3.7V bulb that will focus in this, to use it with a single cell body (E1, FM 1x 16340/1x 18500, etc.)?

Could be but I never seen this size 3.7 volt bulb.

Now I'm wondering about the 1111. Any guesses, anyone?

WA1111 is G4 and won't fit in FM bi-pin socket. Also it is T2.25 and too fat to go inside reflector.

The issue is that this head, together with FM's no-longer-produced custom socket, is engineered to focus with ONLY two lamps; one is the readily available Carly CL1499; the other is the FM1794 (custom-made by Carly for FM), available from only one source (not FM).

Not true.

Last edited:

dcaprilia

Enlightened
Joined
Aug 27, 2009
Messages
405
Location
Philippines
I'll take one black kit and one gray kit.

Paypal sent for E2 mini turbo head in black No.1 and gray No.1.

Thanks

Last edited:

senna94

Flashlight Enthusiast
Joined
Dec 9, 2005
Messages
1,750
Location
Houston, Texas
I will take #2 black kit with USPS Priority shipping to CONUS with DC.

E2 Black Mini Turbo Head $49.00 + USPS Priority w/DC $6.00 = $55.00 total
:paypal:
Payment Sent (Unique Transaction ID #0EF65984V4502661C)

Thanks FM!!

Thinking of all the possibilities this could open up. I am wondering if a McGizmo 2 X AA body with 2 X 14500 cells will work.

Last edited:

Hack On Wheels

Enlightened
Joined
Nov 4, 2007
Messages
774
Location
Canada
Just a couple questions about this... would stock surefire lamps physically not fit? Also, why do you say this is limited to using a CL1499 bulb, would a Strion or TL-3 bulb not work well?

Very nice looking heads regardless!
I'm assuming the Grey would be similar in finish to your E-series bodies?


fivemega

Flashlight Enthusiast
Joined
Jan 28, 2003
Messages
5,550
Location
California

iflyjts

Newly Enlightened
Joined
Jun 28, 2009
Messages
150
Location
USA
Nice work FIVEMEGA as always ! ! !

QUESTION: What is the run-time on this setup using the CL1499 and the IMR 16340 batteries? Thanks in advance...


iflyjts :thumbsup:






lovecpf


paintballdad

Enlightened
Joined
Sep 22, 2008
Messages
529
Location
SoCal
Will the stock Surefire clicky tailcap switches handle the current draw of these lamps?


iflyjts

Newly Enlightened
Joined
Jun 28, 2009
Messages
150
Location
USA
I'll take (1) #2 Gray Kit, and (1) #24 E Series Bi-pin socket, and (2) additional CL1499 bulbs.

:paypal:


thanks,

iflyjts :thumbsup:

Last edited:

fivemega

Flashlight Enthusiast
Joined
Jan 28, 2003
Messages
5,550
Location
California
QUESTION: What is the run-time on this setup using the CL1499 and the IMR 16340 batteries?
15 minutes with pair of IMR16340
And 45 minutes using 2 protected 18500


Will the stock Surefire clicky tailcap switches handle the current draw of these lamps?
This set up takes under 2 Amps and I don't think $urefire clicky fail.
It works for me just fine.


dcaprilia

Enlightened
Joined
Aug 27, 2009
Messages
405
Location
Philippines
Ill also get

(2) E Series Bi-pin socket No.25 and 26. - $54 each

(2) additional CL1499 bulbs- $18

Total $72


iflyjts

Newly Enlightened
Joined
Jun 28, 2009
Messages
150
Location
USA
Any chance that you have any more Gray E series 2x18500 bodies coming
back in stock? I'll take one when you do!

Thanks,

iflyjts :thumbsup:


fivemega

Flashlight Enthusiast
Joined
Jan 28, 2003
Messages
5,550
Location
California
any chance you'll sell me a couple of 1499 bulbs? please let me know either way, thank you.
Sorry,
I don't sell bulbs.
I don't sell bulbs.
[size=+1]I don't sell bulbs.[/size]
[size=+2]I don't sell bulbs.[/size]
[size=+3]I don't sell bulbs.[/size]
[size=+4]I don't sell bulbs.[/size]


lctorana

Flashlight Enthusiast
Joined
Jun 28, 2007
Messages
2,123
Location
Melbourne, Australia
:paypal:for:
#04 Gray kit $49
1 Extra 1499 $9
#27 Socket only $27
International Shipping $5 (please let me know if this isn't enough)
Total $90


Ferry

Newly Enlightened
Joined
Feb 10, 2008
Messages
89
Location
Jakarta - Indonesia
Hi Varooj,

:paypal: (Unique Transaction ID #1NY15363GG442523V)
#05 Black kit $49
1 extra TL-3 bulb $7 (I hope you don't mind..)
International Shipping $5
Total $61


Regards,
FF

Last edited:
