Dual Bored 2P 18650 M*g 1.25D & 2S/2P 2.5D

[SIZE=+3](AVAILABLE)[/SIZE]​

[SIZE=+1]Please allow 7 days to ship[/SIZE]​


[SIZE=+1]Please note: I will not send email or PM to individuals regarding payment confirmation and shipping status.
All these information will be next to your CPF handle in this post.
All 50 States shipping will come with tracking number but for international orders I will provide label number. Sorry, no tracking available for international orders.[/SIZE]






[SIZE=+2]Please read completly and carefully before you pay[/SIZE]

Here is another creation from Fivemega. 3.7 volt, 5800mAh 1.25 M*g or 7.4 volt, 5800mAh 2.5 M*g
As you see in picture, these M*gs are shortened, rethreaded and dual bored to accept two 18650 batteries side by side and connected in PARALLEL. Using pair of AW's new 18650 cells you will get 6800mAh capacity at 3.7 volt. Excellent for P7 or SSt-50/90
Using 2 pairs of AW's new 18650 cells you will get 6800mAh capacity at 7.4 volt in 2.5D host.
Excellent for long run incands.
Outside body is partially grooved only where body has enough thickness and untouched where is bored out to fit batteries. This will prevent body weakening.
Heads are also very fine finned and flutted to manage unwanted heat.
Battery holder is integrated with switch and comes with flashlight. No external battery holder required.
Please make sure both batteries are inserted positive to switch side. Battries not included.
Side of body has charging port to recharge batteries without removing from flashlight and [SIZE=+1]NO[/SIZE] balancing required for 2P version. I will also include male charging jack and rubber plug to seal when is not used.
Any charger for 3.7V Li-ion such as this can be used for 2P version and obviously for 2S/2P version you will need this. Please balance charge all 4 cells after few pack charge.
Switch tower is machinned off and ready to install any LED module and controller.
Advantage of parallel cells are not only to save some space and double the capacity but less load per cell, less voltage drop, longer battery life, longer run time and higher current capability.
All you need to do is solder pair of wire (positive and negative) to switch and connect to controller and/or LED module.
When you hold the flashlight body horizontally, switch button is at 12:00 O'clock, one bore is at 3:00 O'clock, second bore is at 9:00 O'clock and charging port is at 6:00 O'clock.
2S/2P (with switch tower without jack) version is excellent choice for long run ROP High or 5761 (WO tower, with G6.35 socket)
This package will cost you way over what you can get here. Check it out.
Host $22
Cut, rethread $30
Dual bored $25
Outside grooves $30
Head finned/flutted $40
Switch tower cut off $15
Battery holder $30
Charging port $30
Total $222

---
While I charge only:
Host $22
Cut, rethread $10
Dual bored $10
Outside grooves $10
Head finned/flutted $10
Switch tower cut off $5
Battery holder $20
Charging port $10
Total $97
You will never find this kind of prices elsewhere.
Package Sale Price: $97
$8 shipping to States (Priority) for first one then add $6 for each additional.
$16 shipping to international (first class) for first one then add $8 for each additional.
For ducumentation purpose, it is [SIZE=+2]necessary[/SIZE] to post your CPF handle and detail of your order here and paypal note.
Without above information, I will never figure out what the payment is for and from whom.
Paypal: [email protected]
Please PM me for other type of payment.
For ducumentation purpose, it is [SIZE=+2]necessary[/SIZE] to post your CPF handle and detail of your order here and paypal note.
Without above information, I will never figure out what the payment is for and from whom.
Example: NewGee :paypal: for:
#98 Red 1.25D M*g $97
Shipping to States $8
--------------------
[SIZE=+3]2P 18650[/SIZE]

[SIZE=-2]#01 Black 1.25D M*g $97 stub paid shipped 0309114000004628XXXX
#02 Black 1.25D M*g $97 Drywolf paid shipped 23080440000026159505
#03 Black 1.25D M*g $97 choppers paid shipped 03080730000166823270
#04 Black 1.25D M*g $97 UberLumens paid shipped 23082180000028880556
#05 Black 1.25D M*g $97 steffleu paid shipped LC547811005US
#06 Black 1.25D M*g $97 nailbender paid shipped 03092880000110388098
#07 Black 1.25D M*g $97 PhotonAddict paid shipped LC548067169US
#08 Black 1.25D M*g $97 Weld Inspector paid shipped 9505513808427191048567
#09 Black 1.25D M*g $97 n_den payment received shipped 9505513808437285099832
#10 Black 1.25D M*g $97 n_den payment received shipped 9505513808437285099832
#11 Black 1.25D M*g $97 jayrob paid shipped 9505513808438163151857 [/SIZE]
---------------------

---------------------
[SIZE=-2]#01 Red 1.25D M*g $97 pom70 paid shipped LC845286089US
#02 Red 1.25D M*g $97 nailbender paid shipped 0309114000004634XXXX
#03 Red 1.25D M*g $97 Drywolf paid shipped 2308218000002886XXXX
#04 Red 1.25D M*g $97 nickg paid shipped LC845286628US
#05 Red 1.25D M*g $97 CKOD paid shipped 03092880000110413738
#06 Red 1.25D M*g $97 nailbender paid shipped 03092880000110388098
#07 Red 1.25D M*g $97 Scharrlatan paid shipped LC548067040
#08 Red 1.25D M*g $97 X_Marine paid shipped 23082180000028854083
#09 Red 1.25D M*g $97 X_Marine paid shipped 23082180000028854083[/SIZE]

---------------------

---------------------
[SIZE=-2]#01 Blue 1.25D M*g $97 3rdrock paid shipped 0309114000004627XXXX
#02 Blue 1.25D M*g $97 Drywolf paid shipped 2308044000002615XXXX
#03 Blue 1.25D M*g $97 Gino paid shipped 0308073000016681XXXX
#04 Blue 1.25D M*g $97 flashfiend paid shipped 03092880000110435228
#05 Blue 1.25D M*g $97 Jay T paid shipped 03092880000110446538
#06 Blue 1.25D M*g $97 sbelyo paid shipped 03080730000166837161[/SIZE]
---------------------
[SIZE=-2]#01 Pewter 1.25D M*g $97 nailbender paid shipped 2308044000002617XXXX
#02 Pewter 1.25D M*g $97 nailbender paid shipped 2308044000002617XXXX
#03 Pewter 1.25D M*g $97 pom70 paid shipped LC845286013US
#04 Pewter 1.25D M*g $97 LightJunk paid shipped LC845286044US
#05 Pewter 1.25D M*g $97 n_den paid shipped 2308044000002615XXXX
#06 Pewter 1.25D M*g $97 n_den paid shipped 2308044000002615XXXX
#07 Pewter 1.25D M*g $97 erlon paid shipped 2308218000002886XXXX
#08 Pewter 1.25D M*g $97 nailbender paid shipped 2308218000002886XXXX[/SIZE]
================
[SIZE=+3]2S/2P 18650[/SIZE]
================
#01 Black 2.5D M*g $97 FlaCracker paid shipped 03101230000057516172

--------------------
#01 Black 2.5D M*g (NO HEAD) $67 Rommul paid shipped 03112550000058020996
#02 Black 2.5D M*g (NO HEAD) $67 (AVAILABLE)
#03 Black 2.5D M*g (NO HEAD) $67 (AVAILABLE)
--------------------
[SIZE=-2]#01 Red 2.5D M*g $97 Luke-299 paid shipped LC547920172US[/SIZE]
#02 Red 2.5D M*g $97 (AVAILABLE)
--------------------
#01 Red 2.5D M*g (NO HEAD) $67 (AVAILABLE)
#02 Red 2.5D M*g (NO HEAD) $67 (AVAILABLE)
#03 Red 2.5D M*g (NO HEAD) $67 (AVAILABLE)
--------------------
[SIZE=-2]#01 Blue 2.5D M*g $97 J3004 paid shipped LC138287972US[/SIZE]
--------------------
[SIZE=-2]#01 Pewter 2.5D M*g $97 nailbender paid shipped 0309288000011043XXXX
#02 Pewter 2.5D M*g $97 Colonel Sanders paid shipped
#03 Pewter 2.5D M*g $97 spencer paid shipped LC740355964US[/SIZE]
===============
[SIZE=+3]2S/2P 18650[/SIZE] [SIZE=+1]With Swith Tower Without Jack[/SIZE]
===============
[SIZE=-2]#01 Black 2.5D M*g $97 (W/S Tower WO Jack) 325addict paid shipped LC138287884US
#02 Black 2.5D M*g $97 (W/S Tower WO Jack) 357mag1 paid shipped [/SIZE]
---------------------
[SIZE=-2]#01 Red 2.5D M*g $97 (W/S Tower WO Jack) 357mag1 paid shipped 23082180000028872360
#02 Red 2.5D M*g $97 (W/S Tower WO Jack) 357mag1 paid shipped
#03 Red 2.5D M*g $97 (W/S Tower WO Jack) monkeyboy paid shipped LC548067005US[/SIZE]
---------------------
[SIZE=-2]#01 Blue 2.5D M*g $97 (W/S Tower WO Jack) 357mag1 paid shipped 23082180000028872360
#02 Blue 2.5D M*g $97 (W/S Tower WO Jack) CKOD paid shipped
#03 Blue 2.5D M*g $97 (W/S Tower WO Jack) gVp paid shipped LC458383865US [/SIZE]
---------------------
[SIZE=-2]#01 Pewter 2.5D M*g $97 (W/S Tower WO Jack) Steve in SoCal paid shipped 03101230000057505701
#02 Pewter 2.5D M*g $97 (W/S Tower WO Jack) Scott B paid shipped 23082180000028848938
#03 Pewter 2.5D M*g $97 (W/S Tower WO Jack) double0thirteen paid shipped [/SIZE]
---------------------
#01 HA matte grey 2.5D M*g $107 (W/S Tower WO Jack) (AVAILABLE)
---------------------
[SIZE=-2]#01 Gold Plated 2.5D M*g $137 (W/S Tower WO Jack) UberLumens paid shipped 23082180000028880556 [/SIZE]
---------------------
[SIZE=+1]Please find link of my other products[/SIZE] [SIZE=+2]here[/SIZE][SIZE=+1] and click on each link you are interested on.[/SIZE]
---------------------
[SIZE=+3](A V A I L A B L E)[/SIZE]​

Last edited:

fivemega

Well-known member
CPF Supporter
Joined
Jan 28, 2003
Messages
5,135
Location
California
These look very nice. I may be in for one if you or someone could point me to what drop ins I could use. Links would be helpful. Thanks. :wave:
Switch tower is machinned off and ready to install any LED module and controller.
--------------------------
This would make a fun ROP host.
Using AW's new 18650 cells you will get 6800 mAh capacity at 3.7 volt in 1.25D and 6800mAh at 7.4 volt in 2.5D.
--------------------------
Does it mean that this host is for LED only?
LEDs work better with 3.7 volt.
-------------------------
This comes with a plastic lens and reflector correct?
That's correct.
--------------------

I'll have to upgrade that. :twothumbs
It's your option.
------------------------
Using pair of AW's new 18650 cells you will get 6800mAh capacity at 3.7 volt.

That charger will work if you cut the output wires and connect to supplied jack.
Keep in mind when charging current is about 1.2 Amps, charging time will be about 6 hours if batteries are depleted.

-----------------------
Being that the cells are parallel you will not have enough volts to power a ROP.Not to mention that it has no switch tower.:poke:
2P/2S 18650 versions can be used for ROP
-----------------------
My question is how much space is for drivers / heatsink. I presume standard such as britelumens or LITEmania's or mac's are expected, please confirm heatsink compatability.
There are more than enough room for any heat sink ever made for M*g D
Another word, front of C clamp (switch stopper) is completly empty.

-----------------------
No it's good, 4xAW IMR 16340, 2s2p.
It's wasting space for 2S/2P 16340. Why not using 2S/2P 18350?
IMR 18350 will work much better with more current capability and more capacity.

-----------------------
(Further, for 2s18650 you could remove the switch, split the top contacts and create a + and -'ve, reverse one of the cells and isolate tail-spring from the case. Maybe modding the tail contacts you could fit in 2s2p18500's...
2S/2P 18500 won't fit. Part of batteries are in deep bored out body and can't go inside tail cap. Also double bored area is up to bottom of switch and batteries won't go further.
-----------------------
Is there a battery negative contact component not pictured?
That's true. It's not shown in the picture but comes with flashlight.
-----------------------
I'd like a 5 cell cut with body grooves and the head finned and fluted. I realize this is probably one you don't have - I could send one via Amazon, and PayPal for the service.... still $28.00 with shipping to USA 69101?
This thread is not for service and I don't do modification service in small quantity.
All flashlights on post one are already completed in group and quantity to reduce total cost.
Custom service for one flashlight the way you want (if somebody can do for you) will cost way more expensive.

-----------------------

Last edited:

xcel730

Well-known member
Joined
Mar 21, 2008
Messages
1,757
Location
NY
These look very nice. I may be in for one if you or someone could point me to what drop ins I could use. Links would be helpful. Thanks. :wave:


QtrHorse

Well-known member
Joined
May 2, 2008
Messages
1,159
Location
Texas
As FM stated, these would be great for a SST50 or 90 build. The host should also work with Malkoff's new XPG drop-in that has a max of 5.5V rating.


ANDREAS FERRARI

Well-known member
Joined
Aug 24, 2008
Messages
1,041
Location
The Great White North
This would make a fun ROP host.

.....dual bored to accept two 18650 batteries side by side and connected in PARALLEL. Using AW's new 18650 cells you will get 5200mAh capacity at 3.7 volt...

Being that the cells are parallel you will not have enough volts to power a ROP.Not to mention that it has no switch tower.:poke:


Hill

Well-known member
Joined
Apr 11, 2008
Messages
318
Location
MA
Another brilliant and tempting creation.:grin2:

My wallet is screaming.....:mecry:


Linger

Well-known member
Joined
Feb 17, 2009
Messages
1,437
Location
Kingston ON
Wow.
fivemega said:
Switch tower is machinned off and ready to install any LED module and controller.
FM, please include pic with head removed to illustrate top of switch. My question is how much space is for drivers / heatsink. I presume standard such as britelumens or LITEmania's or mac's are expected, please confirm heatsink compatability.


Linger

Well-known member
Joined
Feb 17, 2009
Messages
1,437
Location
Kingston ON
This would make a fun ROP host
Edit: cancel that!

No it's good, 4xAW IMR 16340, 2s2p.

(Further, for 2s18650 you could remove the switch, split the top contacts and create a + and -'ve, reverse one of the cells and isolate tail-spring from the case. Maybe modding the tail contacts you could fit in 2s2p18500's...)


fivemega

Well-known member
CPF Supporter
Joined
Jan 28, 2003
Messages
5,135
Location
California
Does it mean that this host is for LED only?
Thanks!
Joe
Not necessarily but would you spent some time to mode it with 3.7 volt incand?
-------------------
This comes with a plastic lens and reflector correct?

I'll have to upgrade that. :twothumbs
Exactly.
-------------------
Only if you cut output wire and connect it to supplied jack.
-------------------
My question is how much space is for drivers / heatsink. I presume standard such as britelumens or LITEmania's or mac's are expected, please confirm heatsink compatability.
There are more than enough room for any heat sink ever made for M*g D
Another word, front of C clamp (switch stopper) is completly empty.

-------------------
No it's good, 4xAW IMR 16340, 2s2p.
It's wasting space for 2S/2P 16340
2S/3P IMR will work better.

-------------------
(Further, for 2s18650 you could remove the switch, split the top contacts and create a + and -'ve, reverse one of the cells and isolate tail-spring from the case. Maybe modding the tail contacts you could fit in 2s2p18500's...
2S/2P 18500 won't fit. Part of batteries are in deep bored out body and can't go inside tail cap.
